1.A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3ton ZL30 CE wheel loaders
loader 3.0ton ZL30
1.Engine: Cummins/Deutz
2.Power:92KW
3.Bucket Capacity:1.7m3
4.Rated Load:3000kg
Standard packing
Our Main Products Covers
1)Wheel loader D25,ZL08.ZL10,ZL12,ZL16,915,ZL20,ZL30 and ZL50.
2)Site Dumper 2ton, self loading dumper 2ton, 3 ton hydraulic dumper,3 ton dumper with side dumping type,5 ton dumpers.
3) Mini Tractors with different attachments from 25HP to 100HP.
Specifications of ZL30
Specifications |
ZL30 |
Rated bucket capacity |
1.7M3 |
Rated loading weight |
3000kg |
Operating weight |
9970kg |
Max.dump height |
3200mm |
Max.dump distance |
1100mm |
Min. base to the ground |
390mm |
Wheel base |
2750mm |
Track base |
1800mm |
Performance of bucket being set level |
Yes |
Static tilting load at full steering position |
72KN |
Max.breakout force |
138KN |
Max.drawbar pull |
90KN |
Max.grade ability |
30 |
Total time of three(lifting,dumping,lowering) |
11s |
Overall dimensions(length×with×height)mm |
6680×2270×3190 |
Intake method |
Turbocharged intercooled |
Cylinder number |
6 |
Max.torsion |
480Nm |
Engine |
Engine (92KW) Cummins/Deutz |
Rated power |
92kw |
Min.futel consumption |
190g/kw·h |
Rated speed |
2200r/min |
Noise(dB) |
105 |
Transmission |
Gearbox separated from torque converter |
Model of torque devicePattern |
YJ320 |
Pattern |
3-element,single stage |
Pattern of gear boxes |
Full-powershift,countershaft type |
Number of gear shift |
4 forward,2revers |
Max.travel speed |
45km/h |
Main reducer type |
Arc taper gear, moderation of double grade |
Pattern of wheel side moderation |
Single stage planetary |
Tire size |
17.5-25 |
Front tire pressure |
343kpa |
Rear tire pressure |
304kpa |
Steering System |
Articulated and hydraulic steering |
Steering angle(each direction) |
37± 1 |
Min.turning radius(outside of bucket) |
5700mm |
Valve distributing working |
DF25·2C |
Working pumps |
CBGQ2100 |
Brake system |
Air assisted oil disc type four wheel brake |
Service brake |
Air cutting control inner expand hoof |
Fuel tank capacity |
108L |
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
