mini wheel excavator NEW65 excavator
1.Model NEW65
2.Weight(KG):5650
3.Engine:A498BPG
4.Revolving Speed(r/min):2300
Model NEW65 | |
Weight(KG) |
5650 |
|
|
Rated Pressure(Mpa) |
20 |
Pump Flow |
(46+46 ) L/Min |
|
|
Engine |
A498BPG |
Rated Power(KW) |
42 |
2300 |
|
|
|
Gradeability(%) |
36.4 % |
Bucket Digging Force |
47KN |
Max. Traction Force(KN) |
30KN |
Arm Digging Force |
25KN |
Rotation Speed(r/min) |
0~10 rpm |
Mini Ground Clearance(mm) |
240mm |
Wheel Base(mm) |
2310 |
Wheel Tread(mm) |
Front 1665 Back 1570 |
Tyre Type |
7.50-16 |
Drive Type |
4WD |
Gearbox's Control Method |
Mechanical Control |
Gear Number |
Forward ,5 Gears |
|
Backward, 1 Gears |
Max. Traveling Speed |
Forward, ≤40km/h |
|
Backward, ≤5 km/h |
Operating Mothod |
Pilot Control |
|
|
Bucket Capacity(m³) |
0.24 |
Max.Digging Height(mm) |
5840 |
Max.Dumping Height(mm) |
4270 |
Max. Digging Depth(mm) |
3320 |
Max. Digging Radius(mm) |
5830 |
|
|
Back-end swing radius(mm) |
1750 |
Overall Dimension (L*W*H) (mm) |
5610*2120*2700 |
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3)Unparalleled after sales service
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
