4drive&2drive agricultural wheeled tractor

Specifications

Agricultural tractor
1.Equipped with famous engine
2.12F+12R collor shift
3.Good quality Chinese tractor
4. wheeled tractor



Welcome to Qianli Machinery Co., Ltd.

Henan Qianli Machinery Co., Ltd, is a professional manufacturer of agricultural machines. With 25 years development, Qianli now covers an area of 11 hectare and has 13 modernized process lines.  Our products have been exported to many other countries, such as Romania, Russia, Ukraine, Tanzania, Thailand, Australia, etc.





1.QLN504 4WD  55HP  Tractor with cabin









Famous engine featuring strong power, high reliability, and large torque reserve factor.















2.More details



Steering wheel









Comfortable seat









Work device









QLN tractor have over 70 types tractor main in 6 series.Let me show you below:



1.30 series 250-354 (from 25hp-35hp 2/4wd)



2.40 series 400-554B (from 40hp-55hp 2/4wd)



3.50 series 550-654 (from 55hp-65hp 2/4wd)



4.80 series 700-854B (from 70hp -85hp 2/4wd)



5.90 series 800-1004 (from 80hp-100hp 2/4wd)



6.100 series 1104-1304 (from 110hp-130hp 4wd)







Comprehensive product series make your purchasing easily ! ! !













- Famous brand with " QLN " has long history and famous in and abroad;





- Best and famous brand engines which feature large reserve power, low oil consumption, easy starting, and good economic performance;



- Most advanced chasis design, more power and more stable performance;



- Diverse gears, shuttle shift, creeper shift, speed more reasonable, operation comfortable;



- Strong lift force, matching all kinds of agricultural machinery;







3.PARAMETER





Model	QLN 504
Drive type	4×4
Technical parameter
Dimension(L×W×H)(mm)	3980×1635×2130
Wheel base (mm)	1990
Wheel tread F/R (mm)	1400/1300~1600
Adjust method of wheel tread	Level adjustment
Min. ground clearance (mm)	325
Ballast F/R (KG)	144/360
Engine
Engine type	Vertical ;water cooled ;                   4-stroke ;direct injection
Brand	Quanchai ;YTO ; Yuchai
Volume of fuel tank (L)	43
Rated power (kW)	36.8
Rate oil consumption rate	≤2.04
Transmission
Clutch	Single,dry,dual-stage
Gear box	12F+12R
Speed of PTO (r/min)	540/760
Steering system
Steering system type	Hydraulic steering
Working device
Model of suspension mechanism	Rear mounted, 3-point linkage, categoryⅠ or Ⅱ
Tilling depth control type	Floating control (separated)
Max. lifting force at suspension point 610 mm (kN)	≥8.3
Hydraulic output valve	A pair (multi-way valve)
PTO specification	Φ38×8 or Φ35×6 or Φ34.67×21





(1)Equipped with famous engine
(2)12F+12R collor shift
(3)Good quality Chinese tractor

(4)Beautiful wheeled tractor



4. Tractor in the exhibition











5.Kinds of farm equipment









6.Quality guarantee











Customer First,



                Contact us now!!!



With good quality and competitive price, our products have beenexported to Romania, Ukraine,Tanzania, Congo, Iraq,Thailand, Malaysia,Australia, Venezuela,Chile, etc.
