QLN tractor with CE 50hp four-wheel tractor

Specifications

1. E-MARK certificate
2. High agricultural adaptability
3. Reinforced PTO, hi-reliability
4. 50hp four-wheel tractor

QLN-504 50HP High Grade Tractor

Hot Sale in European Market!!!!



50HP QLN TRACTOR



QLN-504 tractor (50HP) represents the new generation of private sector manufacturing in China. A rugged machine built for commercial reliability and endurance.

The machines are simple to operate with operator comfort and safety given the highest priority. The simple easy to access lever system provides the optimum driving experience for the operator. The machine has effortless power steering and very comfortable seating.

The steel construction bonnet and guards a built to last and handle the knocks and bruises. Combine this with the reliable long stroke high torque 4 cylinder easy start diesel engine and you have a machine that is truly a pleasure to work with. Dual hydraulic pumps ensure you always have the hydraulic flow required for steering and powered implements.









1. CE/E-mark and ISO certificate

2. Four-wheel-drive, a well sealed from drive axle

3. Non-maintenance of battery

4. Equipped with famous engine, lower oil consumption, high torque reservoir, excellent starting

5. Excellent working with draft control lever and position control lever, hydraulic steering system.

6. ROPS, canopy, enclosed cabin, multi-way hydraulic valve etc. can be chosen according to working request.



PRODUCTS:





1. E-MARK certificate

2. High agricultural adaptability

3. Reinforced PTO, hi-reliability

4. 50hp four-wheel tractor



Model			QLN-504
Drive Type			4×4
Maximum power of PTO(kW)			27.6
Minimum operation weight (kg)			2220(without cab)/2400(with cab)
Minimum turning radius (mm)			3800±300
Dimensions	Length (including rear suspension) (mm)		3910
	Width (mm)		1635
	Height (to the top of muffler) (mm)		2160
	Wheelbase (mm)		2030
Track	Front wheel (mm)		1280
	Rear wheel (mm)		1310(adjustable)
	Structure weight(kg)		2190(without cab)/2390(with cab)
Engine	Model		A498BT1
	Type		4 Cylinder, Vertical, water cooled, 4 stroke
	Cylinder diameter× stroke (mm)		98×105
	Rated power(kW)		36.8
	Rated rotary speed (r/min)		2400
Transmission	Clutch model		dry double action clutch
	Differential lock		closed,4 planetary gear
	Shift		12F+12R
	Speed (Km/h)	Forward	2.46-32.73
		Rear	2.15—28.69
Hydraulic system	Type		partial separated
	Hydraulic output valve		1 pair or 2-pair
	System pressure (MPa)		18
	3-point suspension		category II
	Function		Load control, position control, load and position individual control
	Maximum lifting force at 610mm behind suspending point (KN)		>10.2
	Steering type		Front wheel hydraulic steering
PTO–Rear	Specification		Φ35×6
	Rotary speed (r/min)		540/760
Traction	Rated traction force (KN)		11.5
	Type		Swing drawbar
	Distance to the ground (mm)		325
Tyre	front wheel /rear wheel		F8.3-20  / R12.4-28
Oil filling capacity	Fuel tank (L)		43
	Oil sump tank (L)		7
	Hydraulic and steering oil (L)		0.8
	Oil for transmission system (L)		20





FARM EQUIPMENTS





EXHIBITION:





If you are interested in our products ,please feel free to contact with us !!!



Cindy Yang



Mob:+86-15515861437



Tel:+86-371-55051327



Fax:+86-371-65316358



E-mail;sales06(at)



Skype;QLN.Cindy.Yang



Website;http://hnqljx.en.china.cn/



 /



http://hnqianli.en.china.cn/







If you are interested in our tractor, we will give you the reasonable price and the best quality guarantees!!
