Specifications
new farm tractors1. E-MARK certificate
2. High agricultural adaptability
3. Reinforced PTO, hi-reliability
With CE certification QLN504 50hp 4wd new farm tractors
Features of farm tractor QLN-504:
modern compact desighed tractor with a rugged chassis
adopt international advanced technology
high capacity dual hydraulic pumps in front steering axle, make steering easy and reliable
logically positioned controls and clear concise instrumentation
high quality high performance engine, oil saving, low noise and low vibrate
easy to operate 3-point linkage, rear remontes,wet disc brakes
cute apparance, any coloer for your choice
Tractor can be with cabin, Air Conditioning, Heater, fan, radio, and etc.
Technical Parameters:
Model | QLN-504 | ||
Drive Type | 4×4 | ||
Maximum power of PTO(kW) | 27.6 | ||
Dimensions | Length (including rear suspension) (mm) | 3910 | |
Width (mm) | 1635 | ||
Height (to the top of muffler) (mm) | 2160 | ||
Wheelbase (mm) | 2030 | ||
Track | Front wheel (mm) | 1280 | |
Rear wheel (mm) | 1310(adjustable) | ||
Structure weight(kg) | 2190(without cab)/2390(with cab) | ||
Minimum operation weight (kg) | 2220(without cab)/2400(with cab) | ||
Minimum turning radius (mm) | 3800±300 | ||
Engine | Model | A498BT1 | |
Type | 4 Cylinder,Vertical, water cooled, 4 stroke | ||
Cylinder diameter×stroke (mm) | 98×105 | ||
Rated power(kW) | 36.8 | ||
Rated rotary speed (r/min) | 2400 | ||
Transmission | Clutch model | dry double action clutch | |
Differential lock | closed,4 planetary gear | ||
Shift | 12F+12R | ||
Speed (Km/h) | Forward | 2.46-32.73 | |
Rear | 2.15—28.69 | ||
Hydraulic system | Type | partial separated | |
Hydraulic output valve | A pair or 2-pair (multi-way valve) | ||
System pressure (MPa) | 18 | ||
3-point suspension | category II | ||
Function | Load control, position control, load and position individual control | ||
Maximum lifting force at 610mm behind suspending point (KN) | >10.2 | ||
Steering type | Front wheel hydraulic steering | ||
PTO–Rear | Specification | Φ35×6 | |
Rotary speed (r/min) | 540/760 | ||
Traction | Rated traction force (KN) | 11.5 | |
Type | Swing drawbar | ||
Distance to the ground (mm) | 325 | ||
Tyre | front wheel /rear wheel | F8.3-20 / R12.4-28 | |
Oil filling capacity | Fuel tank (L) | 43 | |
Oil sump tank (L) | 7 | ||
Hydraulic and steering oil (L) | 0.8 | ||
Oil for transmission system (L) | 20 | ||
Distributorship is widely open to European Market. Welcome to contact for cooperation!
If you are interested in our products, pls feel free to contact us at any time.
