YTO LR diesel engine series
Product:
There are LR-R/A/B/M/N series, More than 80 types of basic models to choose from. Suitable for harvesters and middle size wheeled and crawler tractor, construction, vehicle, marine, generator, general power unit.
Technology:
Deeply cooperation with world famous South-West Research Institute and Ricardo Consulting Ltd., Co., adopting CAD/UG 3D technologies and CAE analysis to fully optimize main components and using world first class port simulation technology to set up advanced technical platform of products.
Structure:
Adopt dry-type sleeves cylinder block with high efficiency inserted oil cooler and single cylinder head with two-valves or four-valves, 6N engines have good stiffness by adopting high strength integral frame in skirt section. 4N engines reduce the vibration to the lowest level by adopting Lanchester balancer.
Basic Parameter | |
Type | In-line, direct injection, water-cooling, four stroke |
Aspiration | naturally aspirated turbocharged turbocharged & after cooled |
Valves | 2valves 4valves |
Cylinder | 4 6 |
Bore (mm) | 100 105 108 110 112 115 |
Stroke (mm) | 120 125 135 |
Displacement (L) | 3.8 4.33 4.58 4.75 4.94 5.13 5.32 6.49 6.87 7.01 7.13 7.4 7.7 7.97 |
