Help CenterGNXW528 Long Depth Soil Drill Machine With Hole Diameter 600mm to 1600mm
Related Products
-
Portable Crawler Type Soil Drill Hole Machine for SaleUS$ 20,000 - 25,000MOQ: 1 Set -
Wheel Type Portable Soil Drill Hole Machine With 360 RotationUS$ 20,000 - 25,000MOQ: 1 Set
-
Homemade Truck Soil Drilling Machine on SaleUS$ 20,000 - 25,000MOQ: 1 Set
-
Wheel Type Soil Drilling Rig MachineUS$ 20,000 - 25,000MOQ: 1 Set
-
Hydraulic Pile Hammer Driving Machine for Soil HoleUS$ 20,000 - 25,000MOQ: 1 Set
PECIFICATION
HOLE DIAMETER :600-1600mm
HOLE DEPTH :20-28m
OVERALL SIZE:10.5*2.6*3.5m
MACHINE WEIGHT:32000kg
ENGINE MODEL :YUNNIE6105/CUMMINS
POWER FORCE:60KN.m
TURENING TYPE : CYLINDER PRESS
ROTATION ANGLE:360°
FUNCTIO1. The folding mast structure, simple structure, good durability, the machine has good stability, save cost and make the maintenance more convenient.
2. Use the guide frame structure, guarantee the verticality of drill pipe and the ground, more convenient construction, improve the efficiency of the construction, increased security.
3. The power head original patent structure design is reasonable, lubrication, reliable and powerful, cost savings, and not easy to damage, easy to maintenance.
4. The main winding: adopt imported hydraulic motor, responsive, can use free down, speed can reach 82 m/min, greatly improve the efficiency of construction. The primary winding is placed in operator right, make the operator can observe to the working condition of main winding, avoid disorderly rope phenomena caused by other factor
Specification | |||
Hole diameter | Mm | 600-1600 | |
Max hole depth | M | 28 | |
Size | Working | mm | 13200*3200*3325 |
Transport | mm | 8200*3200*3325 | |
Weight | kg | 36000 | |
Engine | Model |
| 6105 |
Power | kw/rpm | 110/2100 | |
Type |
| Turbo | |
Power head | Max force | kn-m | 80 |
Speed | r/min | 1-22 | |
Cylinder | Max push power | kn | 150 |
Max lifting force | kn | 100 | |
max route | m | 3 | |
Main winch | Max winch force | kn | 120 |
Max winch speed | m/min | 70 | |
Steel wire Rope diameter | mm | 24 | |
Assistant winch | Force | kn | 60 |
Speed | m/min | 50 | |
Steel wire Rope diameter | mm | 18 | |
Angle of the mast | Left right | ° | ±3 |
Front back | ° | 0-93 | |
Chassis | Max walking speed | km/h | 3 |
Min clearance | Mm | 460 | |
Width crawler | mm | 800 | |
