high quality skid steer loader from china
| GN400 outline dimension | GN400 specification | |||||
| NO | Item | size | NO | Item | parameter | |
| 1 | Max working height(H3) | 2651mm | 1 | Rate load | 400KG | |
| 2 | Max pin height(H2) | 2301mm | 2 | Total weight | 1400KG | |
| 3 | Max dump height(H1) | 1710mm | 3 | Engine | D1803 KUBOTA | |
| 4 | The highest point of discharging distance(L3) | 301mm | 4 | Rotating speed | 2200r/min | |
| 5 | Wheelbase(L) | 800mm | 5 | Engine type | Water cool cylinder three | |
| 6 | Cab height(H) | 1729mm | 6 | Power | 22.8KW(31HP) | |
| 7 | The height from the ground(F) | 141mm | 7 | speed | 0-8Km/h | |
| 8 | Length without bucket(L1) | 2042mm | 8 | Dumping angle | 41° | |
| 9 | Total length(L) | 2655mm | 9 | Turn angle | 360°Steering in place | |
| 10 | bucket width(K) | 930mm | 10 | Departure angle | 24° | |
| 11 | Total width(W)<, /o:p> | 928mm | 11 | Drive type | 4WD | |
| 12 | Tread width,centerline to centerline(P) | 784mm | 12 | Bucket capacity | 0.2m3 | |
| 13 | Tire width(W1) | 175mm | 13 | Tire | 145R12C | |
| 14 | Daparture angle(γ) | 20° | 14 | Hydraulic pump flow | 63L/min | |
| 15 | Dumping angle at max height(β) | 41° | 15 | Pressure | 17MP | |
| 16 | Rollback of bucket on ground(α) | 23° | 16 | fuel tank capacity | 42L | |
| 17 | Min turning radius(R) | 1908 | 17 | Hydraulic oil tank capacity | 42L | |
| 18 | Battery | 36AH | ||||
| 19 | Electric current | 36A | ||||
| 20 | Voltage | 12V | ||||
| 21 | Noise | <=107dB(A) | ||||
| 23 | Moter | Heron | ||||
We are established in 2005,we are devoted ourselves to machine manufacturing for ten years long.
We are professional manufacturer and exporter concerned with the design.Our factory covering an
qrea of 88,000 square meters,now we have over 1,000 employees.We have already received ISO9001
certification.All of our pruducts comply with international quality standards and are greatly appreciated in
a variety of markets around the world.
Our Guarantee:
Service:
1. Excellent after-sale service teams
2. One year guarantee for the whole machine
3. 24hours service by calling or email
4. General inspection on fixing before packing
5. Oversea service center acceptable
Quality control:
1. All products must go through checks before manufacturing process
2. Every production line is equipped in an individual QC to ensure well-done production.
If you are interested in us,you can contact with us,we can give you more demails about our pruducts.We are also pleased to welcome you to visit our factory.^^
