Mini Track Skid Steer Loader

Mini Track Skid Steer Loader photo-1
Mini Track Skid Steer Loader photo-2
Mini Track Skid Steer Loader photo-3
Mini Track Skid Steer Loader photo-4
Mini Track Skid Steer Loader photo-5
US$ 500 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Wolwa
Model Number:
GN280
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name Wolwa
Model Number GN280
Place of Origin Shandong, China
Type Skid Steer Loader
Moving Type Crawler Loader
Dimension(Long * Breadth * High) 2200*800*1302mm
Rated Load 165kg, 165kg
Certification CE & ISO9001:2008
Warranty 1year
After-sales Service Provided Overseas third-party support available

Product Description

Mini Track Skid Steer Loader

GN280 Mini Skid Loader is mechanical equipment with many uses. The fuselage is narrow, easy

handling, can easily and quickly hook up a variety of different functions to realize all kinds of work

widely used in park, courtyard, lawn, garden or any other place in the environment.

GN280 Mini Skid Loader Features

1. Mini skid loader GN280 easy to operate

    Double handle finish walking, lift and skip movements

    Piston motor smoothly

    Four-wheel drive adapt to various environment

   Many forms of pedals let the operation safer and more convenient

   Both servo and standard operation mode

2. Mini skid loader GN280 easy maintenance

    Oil mouth in car in vitro, convenient to replace air filter, oil, filter, spark plug

    The guard plate is convenient, the cover can be opened

3. Mini slide loader GN280 can be configurated with variety of affix, and is interchangeable

between each model.

4. International famous brand engine, stable and reliable.

5. Mini slide loader GN380 many kinds of tires and the track model chosen, more resilient.

6. GN280 mini loader is narrower, only 800 mm wide. Can through narrow places, and have big

fuel tank and the lifting force.

7. Mini skid loader can do much simplified manual labor, improve efficiency



Mini Track Skid Steer Loader Parameters



Mini Track Skid Steer Loader



Item

GN280

Crawler

Solid Tire



Ordinary Tire

Widen Tire

Herringbone Tire

Max. Working Height(H3)

2363 mm

2330 mm

2370 mm

2370 mm

2143 mm

Max. Pin Height(H2)

1800 mm

1767 mm

1807 mm

1807 mm

1796 mm

Max. Dumping Height(H1)

1412 mm

1380mm

1420mm

1420mm

1409mm

Top Dumping Distance(E)

533 mm

485 mm

525 mm

525 mm

514 mm

Ma. Dumping Angle(α3)

29°

29°

29°

29°

29°

Collecting Bucket Angle(α2)

36°

36°

36°

36°

36°

Departure Angle(α1)

13°

10°

14°

14°

12.6°

Total Height(H)

1302 mm

1269 mm

1309 mm

1309 mm

1297 mm

Ground Clearance(H1)

143 mm

110 mm

150 mm

150 mm

138 mm

Wheelbase(L1)

652 mm

652 mm

652 mm

652 mm

652 mm

Length Without Bucket(L3)

1752 mm

1752 mm

1752 mm

1752 mm

1752 mm

Total Width(B2)

800 mm

873mm

876mm

1025mm

1000 mm

Bucket Width(B1)

820 mm

820 mm

820 mm

820 mm

820 mm

Total Length With Bucket

2200 mm

2200 mm

2200 mm

2200 mm

2200 mm

Front Turning Radius(R)

1440 mm

1440 mm

1440 mm

1440mm

1440 mm



Engine



Rated Power

15.435kw(21HP)

Rotational Speed

3600rpm

         Noise

≤95db

Property

Rate Load

165 kg

Bucket Capacity

0.12 m3

Max. Lifting Force

375 kg



Speed

0-5.5 km/h



Operating Weight

Solid Tire

795 kg



Normal Tire

740 kg



Widen Tire

704 kg



Crawler

855kg



Herringbone Tire

890kg





Packaging & Shipping

Mini Track Skid Steer Loader

Company Information

Shandong Wolwa Construction Machinery Co., Ltd, a corporate enterprise of Wolwa Group, is a professional hydraulic excavator manufacturer integrating scientific research, production andsales. Wolwa Group Co., Ltd

has the total assets of 2.5 billion RMB. It has over 80,000 squaremeters of production workshop with

international advanced level and 8,000 squaremeters of R & D center. It has the production capacity with an annual

output of 10,000 sets of construction machinery and 20,000 sets of hydraulic parts. The company has the honors of

National High-tech Enterprise, he Leader of Local SMES and Shandong Top 100 Enterprise.

Our main leading products are DLS865-9A  DLS880-9A  DLS890-9A  DLS100-9A Wheeled Hydraulic Excavator,

DLS880-9A  DLS890-9A Wheeled Sugarcane Wood Loader,  DLS118-9A Wheeled Hydraulic Stacker, DLS865-9B  DLS865-10B  DLS880-9B DLS100-9B  DLS130-9  DLS160-9 Crawler Hydraulic Excavator etc.

We also specializes in the sales of other construction machinery and agricultural equipment such as desiccated

underground crusher, welding workstation, truck cranes,wheel loaders, skid steer loaders,concrete mixer trucks,

forklifts, road rollers, harvesters, tractors, steel bar processing machinery and so on.

Our company has passed the ISO9001:2008 authentication, and got European Union CE certificate. Our products

are exported to many countries such as Russia, Belarus, Iran, Vietnam, Five Central Asian Countries, Africa and

other countries all over the world.
