GN400 Mini Skid Steer Loader for Sale

GN400 Mini Skid Steer Loader for Sale thumbnail-1
GN400 Mini Skid Steer Loader for Sale thumbnail-2
GN400 Mini Skid Steer Loader for Sale thumbnail-3
GN400 Mini Skid Steer Loader for Sale thumbnail-4
GN400 Mini Skid Steer Loader for Sale thumbnail-5
GN400 Mini Skid Steer Loader for Sale thumbnail-6
GN400 Mini Skid Steer Loader for Sale photo-1
GN400 Mini Skid Steer Loader for Sale photo-2
GN400 Mini Skid Steer Loader for Sale photo-3
GN400 Mini Skid Steer Loader for Sale photo-4
GN400 Mini Skid Steer Loader for Sale photo-5
GN400 Mini Skid Steer Loader for Sale photo-6
US$ 500 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Wolwa
Model Number:
GN400
Contact Supplier Request Quote Chat Now
Shandong Wolwa Construction Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name Wolwa
Model Number GN400
Place of Origin Shandong, China
Type Skid Steer Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 2655*928*1729mm
Rated Load 400kg, 400kg
Certification CE & ISO9001:2008
Warranty 1year
After-sales Service Provided Overseas third-party support available

Product Description

GN400 Mini Skid Steer Loader for Sale

GN400 skid steer loader is a small skid steer loader, the body is only 1.729 meters, the minimum

turning radius  less than 2 meters, suitable for small space,  widely used in the botanical garden,

pastures and small projects.

GN400 Mini Skid Steer Loader for Sale  technical parameters

GN400 Mini Skid Steer Loader for Sale

GN400 Outline Dimension



GN400 Specification

Item

size



Item

Parameter

Max. Working Height(H3)

2651mm



Rate Load

400KG

Max. Pin Height(H2)

2301mm



Total Weight

1400KG

Max. Dumping Height(H1)

1710mm



Engine

D1803 KUBOTA

Max. Discharging Distance(L3)

301mm



Rotating Speed

2200r/min

Wheelbase(L)

800mm



Engine Type

Water Cool Cylinder Three

Cab Height(H)

1729mm



Power

22.8KW(31HP)

Ground Clearance(F)

141mm



Speed

0-8Km/h

Length Without Bucket(L1)

2042mm



Dumping Angle

41°

Total Length(L)

2655mm



Turn Angle

360°Steering in Place

Bucket Width(K)

930mm



Departure Angle

24°

Total Width(W)<, /o:p>

928mm



Driving Type

4WD

Wheelbase (P)

784mm



Bucket Capacity

0.2m3

Tire Width(W1)

175mm



Tire

145R12C

Departure Angle(γ)

20°



Hydraulic Pump Flow

63L/min

Dumping Angle at Max. Height(β)

41°



Pressure

17MP

Rollback of Bucket on Ground(α)

23°



Fuel Tank Capacity

42L

Min. Turning Radius(R)

1908mm



Hydraulic Oil Tank Capacity

42L




Battery

36AH









Electric Current

36A









Voltage

12V









21

Noise

≤ 107dB(A)









Moter

Heron



Packaging & Shipping

GN400 Mini Skid Steer Loader for Sale

Company Information

Shandong Wolwa Construction Machinery Co., Ltd, a corporate enterprise of Wolwa Group, is

a professional hydraulic excavator manufacturer integrating scientific research, production

and sales. Wolwa Group Co., Ltd has the total assets of 2.5 billion RMB. It has over 80,000

square meters of production workshop with international advanced level and 8,000 square

meters of R & D center. It has the production capacity with an annual output of 10,000

sets of construction machinery and 20,000 sets of hydraulic parts. The company has the

honors of National High-tech Enterprise, he Leader of Local SMES and Shandong Top 100

Enterprise.

Our main leading products are DLS865-9A  DLS880-9A  DLS890-9A  DLS100-9A Wheeled

Hydraulic Excavator, DLS880-9A  DLS890-9A Wheeled Sugarcane Wood Loader,  DLS118-9A

Wheeled Hydraulic Stacker, DLS865-9B  DLS865-10B  DLS880-9B DLS100-9B  DLS130-9  DLS160-9 Crawler Hydraulic Excavator etc.

We also specializes in the sales of other construction machinery and agricultural equipment

such as desiccated underground crusher, welding workstation, truck cranes,wheel loaders,

skid steer loaders, concrete mixer trucks, forklifts, road rollers, harvesters, tractors, steel bar

processing machinery and so on.

Our company has passed the ISO9001:2008 authentication, and got European UnionCE

certificate.Our products are exported to many countries such as Russia, Belarus, Iran,

Vietnam, Five Central Asian Countries, Africa and other countries all over the world.
