Container Truck Trailer

US$ 1 - 15,000 MOQ: 1 Set

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Max Payload:

45000

Shandong Wolwa Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Max Payload 45000

Place of Origin Shandong, China

Model Number container truck trailer

container truck trailer

Tare Weight	About 7.5T
Dimension	13560mm2490mm1575mm
Loading Capacity (T)	≤ 45 T
Axle	3 axles, 13 T FUWA /Huajing Brand
Rim	9.00-22.5
Tire	12.00R22.5 Chengshan Brand 12pieces
Suspension	Mechanical suspension (America Type)
Spring leaf	90(W)mm13(Thickness)mm10 Layer
King pin	JOST brand 3.5inch bolts type
Support leg	China brand 28Tons (Double speed)
Main beam	Height: 500mm, upper plate is 14mm, middle plate is 8mm, Down plate is 16mm; Material is Q345B Steel.
Side wall	Height is 800mm, you can choose freely.
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber (TKL brand); One piece of 45L air tanks
ABS	Without
Twist Locks	Eight pieces (Lifting type)
Valve	WABCO valve
Light	LED light
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely) (equipped with 1 unit Tire spanner, 1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO
