2 axles full dolly trailer
Tare Weight (Dolly Trailer) |
About 5.6-8T |
Dimension |
12450mm × 2490mm× 1575mm (Size can be tailored to suit individual needs.) |
Loading Capacity (T) |
≤ 45 T |
Axle |
13 T/16T, FUWA /BPW /Huajing Brand |
Rim |
9.00-22.5 9.75-22.5 |
Tire |
12.00R22.5/ 315 80R22.5 |
Suspension |
Mechanical suspension (German or American type) Or Air suspension (Chinese or BPW brand ) |
Spring Leaf |
90(W)mm×13(Thickness)mm×10layers or 100mm×12mm×12layers |
King Pin |
JOST brand 2.0 or 3.5inch (bolted or welded type) (Optional)or use turntable (also known as the Fifth Wheel) (Diameter:1.1m) |
Draw Bar |
4×4 or 4×6mm square tube (length: 1.4m ) |
Tractor Hook |
DN50 |
Landing Gear (support leg) |
This dolly trailer does not need landing gear. |
Main Beam |
Height: 500mm Upper plate: 14mm Middle plate: 8mm Bottom plate: 16mm Material: Q345B steel |
Side Beam |
16mm or 18mm channel steel (Material:Q235steel ). |
Bottom Platform |
3mm-thick checkered plate |
Brake Chamber |
WABCO RE 6 relay valve; T30/30+T30 spring brake chamber (TKL brand); 45L air tanks (Specially intended for oversea markets) |
ABS |
Optional |
Twist Locks |
Four ,Eight or Twelve pieces (lifting type or screw type) |
Valve |
WABCO valve |
Light |
LED light(Specially intended for oversea markets) |
Voltage |
24V |
Socket(Receptacle) |
7-pin Socket (for 7 wire harness) |
Tool Box |
1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
Painting |
Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
Shipping Terms |
Transported by the bulk carrier in an RORO or 40HQ container. |
