6 Wheel China Dump Truck for Sale

Name: 6 Wheel China Dump Truck for Sale
Brand: WOLWA
SKU: 140741036
Availability: InStock

US$ 45,000 - 55,000 MOQ: 1 Set

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

Shandong Wolwa Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification CE

Size 11280*2495*3970mm

OEM No. GNWOLWA001

Max Payload less than 80 t

Place of Origin Shandong, China

Brand Name WOLWA

Model Number GNDT64

Product Description

Semi Trailer Dimension	11280×2495×3970mm (Outside Dimension)10500×2300×1700mm (Inside Dimension)
Tare Weight	About 15600kg
Total Volume (m³)	37 m³ or less than 80tons
Side wall thickness (mm )	6mm Q235 steel
Bottom plate thickness(mm)	8mm /Q235 steel
Lifting system	Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder
Chassis
Main Beams	Height:500mm Upper plate: 16mm Middle plate: 8mm (2-in-1 or 3-in-1 plate) Lower plate: 18mm Material :Q345B steel
Axle	3 axles, FUWA/HUAJING brand 16tons per axle
Landing Gear	JOST (D200T) or Chinese brand 28T
King Pin	JOST 2.00 or 3.5 inch bolt-in king pin
Suspension	Mechanical suspension/ America type /
Leaf Spring	90(W)mm×13(Thickness)mm×10 layers
Pneumatic Braking System	WABCO RE 6 relay valve; Spring brake chamber; 45L air tank
Rim	9.00-22.5/8.00-20/8.5-20 China Brand
Tire	/12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Various tire brands are available.
ABS	Optional
Painting	Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats.
Accessories	One standard tool box
Shipping Terms	By Bulk Cargo or RORO The trailer size can be designed according to your special requirements. You can choose a 6×4 model truck for use with your rear dump semi
