Semi-Trailer Type 12.5m Trailer 3 axles Flatbed semi trailer 40 TONS
Low Price Chinese Low-Bed Semi-Trailer, Flatbed Trailer on sale
40 TONS FLATBED SEMI TRAILER |
|
|||||||||||
DIMENSIONS | ||||||||||||
Tare weight |
7000kg |
Payload |
40000 kg |
|||||||||
Overall length |
12500mm |
Overall width |
2500mm |
Overall height |
1600mm |
|||||||
SPECIFICATION | ||||||||||||
Chassis |
Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Aac processes. Top flange 14mm, width 140mm; Middle Flange 6mm;bottom flange16mm, width 140mm |
|||||||||||
Axle |
Number |
3 |
Brand |
Fuwa |
Capacity |
13T |
||||||
Suspension |
Mechanical suspension or air suspension |
|
||||||||||
Leaf spring |
Leaf spring or air bag |
|||||||||||
Floor |
3mm |
|||||||||||
Tire |
13R22.5 |
|||||||||||
Wheel rim |
9.75 |
|||||||||||
Kingpin |
2’’ bolt-in king pin |
|
||||||||||
Landing gear |
two-speed,manual operating ,heavy duty landing gear |
|||||||||||
Twist lock |
12 no.of ISO twist lock for 1x20ft,2x20ft,1x40ft container |
|||||||||||
Vehicular applications |
Container (20ft.40ft..) transport |
|||||||||||
Drawing and packing |
Including |
|||||||||||
Braking system |
RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
|||||||||||
Paiting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
|
||||||||||
Accessories |
One standard tool box |
|||||||||||
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
