High Quality 21.6KW Diesel Engine Driven Portable Air Compressor Atlas Copco XAS47
Trailer Mounted Type Mobile Air Compressor, Screw Air Compressor 91cfm
Free Air Delivery 2.6m3/min
Atlas Copco Portable Air Compressor Features
1) HardHat
2) Full compliance with 2000/14/EC, the latest European Outdoor Noise Directive
3) Years of experience and ongoing investment
4) Guaranteed free air delivery in accordance with ISO 1217 ed. 3 1996 annex D
5) A combination of a Polyethylene upper body and a chassis with a KTL epoxy layer coating with powder coat paint finish
6) Wide-opening canopy and removable side panels
7) High capacity transparent fuel tank
8) Few moving parts
9) Controls grouped on one panel
10) Engine speed adapts to air demand
11) Compliant with exhaust emission standards 97/68/EC Com III (Europe) & EPA Tier II (U.S.)
12) Long service intervals
13) Complete option list
Technical Parameter
Compressor Data |
XAS47 |
|
|
Free Air Delivery @ Normal Working Pressure |
43 L/S (2.6 m³/min ) |
Normal Working Pressure |
7 bar |
Minimum / Maximum Unloading Pressure |
2.9 / 8.7 bar |
|
|
Compression Stages |
1 |
Air Receiver Capacity |
10.7L |
Compressor Oil Capacity |
8 L |
Approximate Air Outlet Temperature |
90°C (Standard) |
Typical oil content of compressed air |
<5 mg/m³ |
|
|
Fuel Tank Capacity |
40L |
Outlet Valve Configuration |
3 x 3/4” G, 1 x 1.5” G |
|
|
Nominal working condition |
Inlet pressure 1bar,Humidity0%,Temp20 °C |
Sound Pressure Level (ISO2125) |
70dB(A) +/- 3 |
|
|
Maximum Ambient Temperature at sea level |
45 °C |
Maximum Altitude |
5000 m |
Minimum Starting Temperature |
-10 °C / -20 °C (with assist) |
|
|
Diesel Engine Data |
DEUTZ F2M2011 |
|
|
Horsepower Developed @ Rated Speed |
21.6 kW |
Cylinders |
2 |
Cooling System |
Oil |
Engine Coolant Capacity |
-- |
Engine Oil Capacity |
6.5 Liter |
|
|
Unloaded Speed / Maximum Loaded Speed |
1850 / 2400RPM |
Fuel Consumption @ 0% Load / 100% Load |
1.9 / 6 kg/h |
|
|
Dimensions |
Standard Towing Speed 20 km/h |
Length |
2970 mm ( within towbar ) |
Width |
1410 mm |
Height |
1258 mm |
Weight ( filled with oil & coolant , Initial fuel ) |
750 kg |
Diesel Driven Portable Air Compressor Series
Working pressure (bar) |
Air delivery |
Model |
Engine |
Compression stage |
||||
Normal |
Range |
m3/min |
L/S |
Brand |
Model |
Motor power |
||
7 |
4/8.8 |
2.0 |
33 |
XAS37 Kd |
KUBOTA |
D905 |
18.5KW |
1 |
7 |
4/8.8 |
2.5 |
43 |
XAS4 Kd |
KUBOTA |
D1105 |
19.4KW |
1 |
7 |
4/13.5 |
1.92 |
37 |
XAHS37 Dd |
DEUTZ |
D2011L02 |
21.6KW |
1 |
7 |
3.6/8.7 |
3.0 |
50 |
XAS57 Dd |
DEUTZ |
D2011L02 |
23.3KW |
1 |
7 |
2.9/8.7 |
3.7 |
62 |
XAS67 Dd |
DEUTZ |
F3M2011 |
32.5KW |
1 |
7 |
3.3/8.7 |
4.3 |
72 |
XAS77 Dd |
DEUTZ |
F3M2011 |
31.5KW |
1 |
7 |
4/8.5 |
5.3 |
89 |
XAS97 Dd |
DEUTZ |
F3M2011 |
36KW |
1 |
10.3 |
4/11.8 |
10.0 |
166 |
XATS156 Dd |
DEUTZ |
BF4M2012C |
55KW |
1 |
7 |
4/8.5 |
7.5 |
125 |
XAS137 Dd |
DEUTZ |
BF4M2011 |
58KW |
1 |
12 |
4/13.5 |
5.6 |
93 |
XAHS107 Dd |
DEUTZ |
BF4M2011 |
58KW |
1 |
14 |
4/15.5 |
8.0 |
133 |
XAVS136 Dd |
DEUTZ |
BF4M2012C |
88KW |
1 |
7 |
4/8.5 |
11.1 |
185 |
XAS186 Dd |
DEUTZ |
BF4M2012C |
88KW |
1 |
12 |
4/13.5 |
10.5 |
173 |
XAHS186 Dd |
DEUTZ |
TCD2013L04 |
104KW |
1 |
13.8 |
4/15.3 |
11.3 |
188 |
XAVS196 Dd |
DEUTZ |
BF4M1013FC |
118KW |
1 |
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
