XGMA Motor Grader for sale
XGMA Brand XG3180C Motor Grader
100HP, 135HP, 165HP, 180HP, 215HP, 230HP, 260HP, 300HP Motor Grader
Model |
XG3180C |
Engine | |
Manufacturer |
Dongfeng Cummins Corporation |
Model |
6BTAA5.9-C180 |
Rated Power (kw/hp) |
132/180 |
Rated Speed (rpm) |
2200 |
Blade | |
Height× String Height (mm) |
3965×610 |
Reversing Angle (°) |
360 |
Max. Blade Angle (°) |
90 |
Cutting Depth (mm) |
500 |
Drive Type |
Motor + worm case |
Transmission | |
Type |
Electro hydraulic gearshift |
Number of Gears |
F6/R3 |
Forward Speed (Km/h) |
5.0, 8.7, 11.4, 19.3, 23.6, 37 |
Reverse Speed (Km/h) |
5.0, 11.4, 23.6 |
Drive Type |
Rear-axle drive |
Max. Traction Force (KN) |
≤84 |
Tyre SPEC |
17.5-25 |
Front Axle | |
Wheel Lean Angle: (°) |
±17 |
Steering Angle: (°) |
±45 |
Oscillation Angle: (°) |
±15 |
Ground Clearance: (mm) |
430 |
Articulation Angle (°) |
25, right and left |
Type of Service Brake |
Hydraulic disc brake |
Type of Parking Brake |
Hand-operated shoe-type brake |
Total Weight (Kg) |
15500 |
Basic Overall Dimensions (mm) (L×W×H) |
8890×2595×3400 |
Full Overall Dimensions (mm) (L×W×H) |
10530×2750×3400 |
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
