Cheap sale 50Ton crawler crane QUY50A in good working
- 100 Unit / Units per Month
- Shanghai Qingdao Tianjin
- T/T L/C D/P D/A Credit Card
- CCS, BV, ABS Approved Marine Ship Telescopic Folding Arm Crane
- China Supplier Single-Arm Rack Floating Crane for Bulk Cargo
- Barge Mounted Crane for Bauxite Discharging Transfer From Vessel to Barge
- Port Grab Crane Coal Bauxite Sand Stone Unloading Crane
- Fixed Type Lattice Boom Port Crane Heavy Duty
- Lattice Boom Port Fixed Crane Widely Usage with Customized Color
Product Details
Condition: | New | Application: | Construction,Mining and others | Rated Loading Capacity: | 50 ton |
Rated Lifting Moment: | 203.5 t.m | Max. Lifting Load: | 50ton | Max. Lifting Height: | 52m |
Place of Origin: | Jiangsu, China | Brand Name: | XCMG | Model Number: | QUY50A |
Certification: | ISO,CE | Warranty: | 1 year warranty | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
XCMG Crawler Crane
CHINA popular XCMG 50 ton Crawler Crane QUY50A hot sale
Introduction of XCMG Crawler Crane QUY50A :
XCMG Crawler Crane QUY50A is designed and developed independently in absorption of foreign advanced technology and combined with China domestic work conditions. It features hydraulic drive, full swing and lattice boom, and also the first one adoption of pilot proportional control in China domestic crawler cranes. This crane is easy operation, stable travel and reasonable arrangement in structure. The maximum lifting capacity is 50t, boom length 13m~52m, jib length 9.15m~15.25m. This crane is suitable for lifting and installation job in construction site, mine, factory and dockside. Optional mechanical grab is available for earth moving and stacking work.
Parameters of XCMG Crawler Crane QUY50A :
QUY 50A Technical Parameters | ||
Descriptions | Unit | Data |
Engine |
| D6114ZG2B, |
Engine output and rotate speed | kW/r/Min | 128/2000 |
Lifting torque | t.m | 180 |
Max. lifting capacity | t | 50 |
Boom length | m | 13-52 |
Length for fixed jib | m | 9.15-15.25 |
Lifting capacity of jib | t | 5 |
Hoisting | m/min | 70;35 |
Boom derricking up and down | m/min | 45 |
Max. slewing speed | r/min | 2.7 |
Travel | km/h | 1.1 |
Gradeability | % | 40 |
Groundpressure | Mpa | 0.069 |
Weight of the crane(basic boom and 50t hook) | t | 50 |
Overall dimensions | mm | 6745×3300×3080 |
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
