BOMR FIAT Gearbox Farm Diesel Tractor (454 Shuttle Shift)

BOMR FIAT Gearbox Farm Diesel Tractor (454 Shuttle Shift) thumbnail-1
BOMR FIAT Gearbox Farm Diesel Tractor (454 Shuttle Shift) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Luoyang Boma Agricultural Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate EPA
Brand Name BOMR
Model Number 454
Place of Origin Henan, China

Specifications

1. 12+12 shuttle shift
2. Turbo charge
3. Italy fiat chassis
4. Increase 30% efficiency
5. Save 25% of fule

The characteristic of tractor from 40hp to 60hp

  1. Our tractors have 16 shifts, 12 forward shifts and 4 reverse shifts. More shift, reasonable speed assign, have suitable economy shift, more saving fuel.
  2. Force buried lifter (force, position comprehensive control and floating control) is using reliably and mending conveniently. Lifters’ oil cylinder diameter is 100mm. The lift capacity can reach 1.4 tons.
  3. Gearbox and rear axle use engagement sleeve shift. Shifting flexibly and stably, never neutral.
  4. Basic unit include double acting clutch. When you shifting or slowing down, it is not affect operate the agricultural implements. It can meet customer’s different requirements when using tractor in the farm.
  5. More tractors’ lamps than other same products. It is more bright and safety when driving in the night.
  6. Strainer is fit in the front of water tank; it can avoid hays and sundries to block up water tank. Strainer is convenient for loading or unloading and cleaning
  7. Reinforced traction system, the height is adjustable.

  8.     Reinforced 3 point-suspension postposition is stronger, using reliable and long life. The bottom tie rod can float.

  9.     Final drive transmission use planetary reducer structure. Large transmission ratio, load bearing equality, stably transmission, little noise and long life using

 10.   Our power take-off has 3 types: 540/760r/min, 540/1000r/min,and 760/1000r/min . It has high efficiency.

 11.   Use national famous brand engine, (like Xinchai (40hp-50hp), Lijia (55hp-60hp) and Jiangdong Brand) and planetary reducer start motor. It starts well and driving strongly.

 12.   Front and rear wheel tread are adjustable. So our tractors are suitable for use in different farmland

.

The Main Specification of Bomr 45hp to 60hp tractor
Tractor Model 450 454 500 504 550 554 600 604
General Specification Driver Type 4×2 4×4 4×2 4×4 4×2 4×4 4×2 4×4
Length×width×Height(mm) 3700×1615×2200 3700×1615×2216 3700×1645×2230 3700×1645×2250 3700×1645×2080 3700×1645×2065 3700×1645×2080 3700×1645×2065
Traction force(KN) 10 10.5 10.7 11.7 11.8 12.8 12.8 14
Steering hydraulic hydraulic hydraulic hydraulic hydraulic hydraulic hydraulic hydraulic
Wheel base(mm) 1940 1955 1940 1955 1955 2010 1955 2010
Front wheel tread(mm) 1320-1620 1250 1330-1630 1250 1330-1630 1250 1330-1630 1250
Rear wheel tread(mm) 1300-1600 1300-1600 1300-1600 1300-1600 1300-1600 1300-1600 1300-1600 1300-1600
P.T.O.Max.Power(Kw) 28.1 28.1 31.3 31.3 34.3 34.3 37.5 37.5
Ground clearance(mm) 380 300 400 300 400 300 400 300
Engine Type 495BT 495BT 498BT 498BT SL4105ABT  SL4105ABT  SL4105ABT SL4105ABT
Bore×Stroke(mm) 95×105 95×105 98×105 98×105 105×117 105×117 105×117 105×117
Rated revolution (r/min) 2300 2300 2200 2200 2300 2300 2300 2300
Max.torque(n.m) ≥169 ≥169 ≥203 ≥203 ≥209 ≥209 ≥220 ≥220
Speed of Max.torque r.p.m. ≤1725 ≤1725 ≤1650 ≤1650 ≤1725 ≤1725 ≤1725 ≤1725
Transmission Clutch Dual-stage clutch
Gear box 12F+4R
Working device Lifter tilling depth control Forced buried
Max.lifting capacity( KN ) 7.4 7.4 8.3 8.3 9.1 9.1 9.9 9.9
Suspension type Class 1  3-Point hitch
Speed of P.T.O.(r/min) stardard;540/720;optional:540/1000,720/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
