BOMR FIAT Gearbox Diesel Wheeled Tractor (550 Swing Traction)

Luoyang Boma Agricultural Engineering Machinery Co., Ltd.
BOMR FIAT Gearbox Diesel Wheeled Tractor (550 Swing Traction) thumbnail-1
BOMR FIAT Gearbox Diesel Wheeled Tractor (550 Swing Traction) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Certificate Other, GB/T II
Brand Name BOMR
Model Number 550
Place of Origin Henan, China

Specifications

1, 12+12 shuttle shift
2. Turbo charge
3. Italy fiat chassis
4. Increase 30% efficiency
5. Save 25% of fule





Tractor Characterstics:

1, Gear box and rear axle will be collar shift, light and flexible, smooth and reliable and never out of gear.

2,12 forward gears and 4 backward gears in proper speed arrangement. Proper and economic gear will save fuel.

3, Force lifter (power and position general control and float control) offers reliable use and easy maintenance. Lifter cylinder will be 100mm with great lifting power up to 1.4t.

4, Machine has compact structure with small axial distance for easy steering.

5, Double action clutch will not affect tool operation in shifting gear, satisfying field operation.

6, Wet disk brake (2 disks) is smooth and reliable with long service life.

7, Steering device will have full hydraulic steering, being light and flexible.

8, Maintenance free battery is installed with more convenience.

9, Bolt differential lock is installed in prevention of side sliding going up slope or in rainy day operation with superb mobility.

10.  Space between front and back wheels is adjustable and suitable for farming requirement in different areas.

11.  Full range models are available. Lighting is very effective and safe for driving in night.

12.  Water tank has a large surface for radiation in proper arrangement without boiling.

13.  Strengthened type with height adjustment.

14.  Rear three point suspension, reinforced and reliable, down lever can be floated.





BOMR FIAT Gearbox diesel wheeled tractor (550 Swing traction)BOMR FIAT Gearbox diesel wheeled tractor (550 Swing traction)BOMR FIAT Gearbox diesel wheeled tractor (550 Swing traction)BOMR FIAT Gearbox diesel wheeled tractor (550 Swing traction)



BOMR FIAT Gearbox diesel wheeled tractor (550 Swing traction)







The Main Specification of Bomr 50hp to 60hp tractor
Tractor Model550554600604
General SpecificationDriver Type4×24×44×24×4
Length×width×Height(mm)3700×1645×20803700×1645×20653700×1645×20803700×1645×2065
Traction force(KN)11.812.812.814
Steeringhydraulichydraulichydraulichydraulic
Wheel base(mm)1955201019552010
Front wheel tread(mm)1330-163012501330-16301250
Rear wheel tread(mm)1300-16001300-16001300-16001300-1600
P.T.O.Max.Power(Kw)34.334.337.537.5
Ground clearance(mm)400300400300
EngineTypeSL4105ABT SL4105ABT SL4105ABTSL4105ABT
Bore×Stroke(mm)105×117105×117105×117105×117
Rated revolution (r/min)2300230023002300
Max.torque(n.m)≥209≥209≥220≥220
Speed of Max.torque r.p.m.≤1725≤1725≤1725≤1725
TransmissionClutchDual-stage clutch
Gear box12F+4R
Working deviceLifter tilling depth controlForced buried
Max.lifting capacity( KN )9.19.19.99.9
Suspension typeClass 1  3-Point hitch
Speed of P.T.O.(r/min)stardard;540/720;optional:540/1000,720/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
