5ton Diesel Forklift Truck

5ton Diesel Forklift Truck photo-1
5ton Diesel Forklift Truck photo-2
5ton Diesel Forklift Truck photo-3
5ton Diesel Forklift Truck photo-4
US$ 13,500 - 15,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SHOUGONG
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name SHOUGONG
Model Number CPCDSG50F
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 5000kg
Max. Lifting Height 3000mm
Min. Lifting Height 150mm
Fork Length 1220mm
Fork Width 150mm
Overall Dimensions 4350*1400*2330mm
Certification CE/ISO9001
After-sales Service Provided Engineers available to service machinery overseas

5ton Diesel Forklift Truck



Product Description



CPCDSG50F 5000KG Diesel Forklift Truck

Advantage

1. 5000KG Small forklift Truck with strong engine system

2. High quality imported separate combination instrument

3. Wide visible range during  operation ensures the safety and accuracy of work.

4. Preventing slope sliding function

5. Super cooling system



5ton Diesel Forklift Truck



5ton Diesel Forklift Truck



5ton Diesel Forklift Truck



PrametersCPCD50F
Load capacity: (kg) 5000
Load center: (mm)  500
Overall height fork raised (with backrest): (mm) 4265
Max lifting height std: (mm)  3000
Free lift: (mm)  150
Overall height (fork lowered, upright): (mm) 2330
Backrest height (from upper face of forks): (mm)1275
Overall length (with forks): (mm) 4350
Overall length (without forks): (mm) 3150
Overall height (overhead guard): (mm) 2330
Overall width: (mm) 1400
Fork length: (mm) 1220
Fork thickness: (mm) 55
Fork width: (mm)  150
Lateral fork (outside fork): (mm) 1350
Overhead guard clearance (from seat face): (mm) ≥1000
Front overhang: (mm) 565
Rear overhang: (mm) 562
Wheelbase: (mm) 2150
Tread (front tires): (mm)  1180
Tread (rear tires): (mm) 1190
Min. under clearance (bottom of mast): (mm)  170
Min. turning radius: (mm)  3000
Min. intersecting aisle: (mm)  2750
Titling angles (forward/backward): (º) 6/12
Lifting speed (with load/without load): (mm/s) 375/520
Lowering speed (with load/without load): (mm/s) 400/300
Max driving speed (with load/without load): (km/h) 20/24
Max. gradeability: (%)20
Front/Driving/Wheel Rear Steering Wheel: yes
Weight distribution with load (front/rear): (%) 85%/15%
Weight distribution without load (front/rear): (%) 35%/65%
Battery voltage/Capacity: (v/Ah)2*80
Total weight: (kg) 6800
Engine Power Type:  59kw
Diesel  Engine Fuel tank capacity: (L) 70













Contract: Frank Yang

MOB:       +86 152-6575-5218

Skype:     Frankyang23

Email:     Frank at





Our Services



SHANDONG SHOUGONG MACHINERY CO., LTD.

Website Address:







  • We'll be on service whenever you need us.
  • We have professional production, sales and after-sales team.
  • With ten years production and exportation, a comfortable and reliable service will provided to you for your procurement.
  • If you have any questions about 5000KG Small Forklift Truck, please send a message.









Company Information



SHANDONG SHOUGONG MACHINERY CO., LTD.

Website Address:

Shandong Shougong Machinery Co.,Ltd is a subsidiary company of Shandong Brother Industry Group, located in Weifang, Shandong, China. With ten years production and export, our machines have been recognized and got good reputation by customers from all over the world. We have got ISO9001: 2000 international quality management system and CE,GOST for most of our machines.Our company have professional teams for production, sale and after-sales service, we also have long-term cooperated shipping forwarders as our partner to delive...

   We always insist on credit and trust during business cooperation, we would like to make friends at first then start business cooperation. Hopefully, you can also agree with us and we could become good friends and business partners.
