SHOUGONG CPCDSG100F 10000KG Small Forklift Truck

SHOUGONG CPCDSG100F 10000KG Small Forklift Truck thumbnail-1
SHOUGONG CPCDSG100F 10000KG Small Forklift Truck photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SHOUGONG
Contact Supplier Request Quote Chat Now
Shandong Brother International Trading Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name SHOUGONG
Model Number CPCDSG100F
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 1000kg
Max. Lifting Height 3000mm
Min. Lifting Height 195mm
Fork Length 1220mm
Fork Width 175mm
Overall Dimensions 5480*2275*2585mm
Certification CE
After-sales Service Provided No overseas service provided



Product Description



CPCDSG100F 10000KG Small Forklift Truck

Advantage

1. 10000KG Small forklift Truck with strong engine system

2. High quality imported separate combination instrument

3. Wide visible range during  operation ensures the safety and accuracy of work.

4. Preventing slope sliding function

5. Super cooling system



SHOUGONG CPCDSG100F 10000KG Small Forklift Truck

SHOUGONG CPCDSG100F 10000KG Small Forklift Truck



PrametersCPCD100F
Load capacity: (kg) 10000
Load center: (mm)  600
Overall height fork raised (with backrest): (mm) 4297
Max lifting height std: (mm)  3000
Free lift: (mm)  195
Overall height (fork lowered, upright): (mm) 2850
Backrest height (from upper face of forks): (mm)1015
Overall length (with forks): (mm) 5480
Overall length (without forks): (mm) 4280
Overall height (overhead guard): (mm) 2585
Overall width: (mm) 2275
Fork length: (mm) 1220
Fork thickness: (mm) 80
Fork width: (mm)  175
Lateral fork (outside fork): (mm) 1790
Overhead guard clearance (from seat face): (mm) ≥1000
Front overhang: (mm) 718
Rear overhang: (mm) 850
Wheelbase: (mm) 2500
Tread (front tires): (mm)  1600
Tread (rear tires): (mm) 1700
Min. under clearance (bottom of mast): (mm)  250
Min. turning radius: (mm)  3900
Min. intersecting aisle: (mm)  3540
Titling angles (forward/backward): (º) 6/12
Lifting speed (with load/without load): (mm/s) 390/280
Lowering speed (with load/without load): (mm/s) 410/380
Max driving speed (with load/without load): (km/h) 26/30
Max. gradeability: (%)20
Front/Driving/Wheel Rear Steering Wheel: yes
Weight distribution with load (front/rear): (%) 75%/25%
Weight distribution without load (front/rear): (%) 46%/54%
Battery voltage/Capacity: (v/Ah)2-12V/80AH
Total weight: (kg) 12510
Engine Power Type: 80.9kw
Diesel  Engine Fuel tank capacity: (L) 120





Contract: Troy Tian

MOB:       +86 132-5809-9028

Skype:     troy.tian1987

Email:     troy at





Our Services



SHANDONG SHOUGONG MACHINERY CO., LTD.

Website Address:







  • We'll be on service whenever you need us.
  • We have professional production, sales and after-sales team.
  • With ten years production and exportation, a comfortable and reliable service will provided to you for your procurement.
  • If you have any questions about 10000KG Small Forklift Truck, please send a message.









Company Information



SHANDONG SHOUGONG MACHINERY CO., LTD.

Website Address:

Shandong Shougong Machinery Co.,Ltd is a subsidiary company of Shandong Brother Industry Group, located in Weifang, Shandong, China. With ten years production and export, our machines have been recognized and got good reputation by customers from all over the world. We have got ISO9001: 2000 international quality management system and CE,GOST for most of our machines.Our company have professional teams for production, sale and after-sales service, we also have long-term cooperated shipping forwarders as our partner to delive...

   We always insist on credit and trust during business cooperation, we would like to make friends at first then start business cooperation. Hopefully, you can also agree with us and we could become good friends and business partners.
