Zl18 Wheel Loader

Zl18 Wheel Loader thumbnail-1
Zl18 Wheel Loader photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
GP
Model Number:
ZL18
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name GP
Model Number ZL18
Place of Origin Shanghai, China
Type Mini Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 5800*1730*2800mm
Rated Load 1800kg

Specifications

The front frame adopts the box-type structure to ensure the reliable operation

1.STEYR diesel engine 2.Single-phase 3. Power and driving system combine in optimize way





WHEEL LOADER Model
Item Specification ZL18 ZL20 ZL28 ZL30 ZL30A
1 Rated weight 1800KG 2000KG 2800KG 3000KG 3000KG
2 Rated capacity 1.03m³ 1.3m3 1.6m3 1.7m3 1.7m3
3 Operating weight 4000KG 7480KG 6000KG 9500KG 9500KG
4 Model of engine Weifang ZH4102 weifang ZH4102 luotuo YTR4108 xichai 6110 DEUTZ TD226B
5 Rated power 50KW/47 KW 45KW 55KW 85KW 92KW
6 Rated speed 2200r/min 2400rpm 2400r/min 2400r/min 2300r/min 2300r/min
7 Max .dump height 3200/3700/4500mm 2800mm 3200/3500mm 3020/3250mm 3250mm
8 Max .dump reach ≥930mm 885mm 1084mm 1200mm 1200mm
9 Min .ground clearance 310mm 310mm 310mm 380mm 380mm
10 Wheel base 2160mm 2150mm 2470mm 2760mm 2760mm
11 Tread 1080mm 1440mm 1380mm 1800mm 1800mm
12 Lifting time 4s Total time:9.8s Total time:11.3s Total time:11s Total time:11s
13 Lowering time 3s
14 Unloading time 2s
15 Max.breakout force 32KN 48.87KN 70KN 138KN 138KN
16 Min.turning radius 3500mm 4239mm 4500mm 5700mm 5700mm
17 Overall dimensions(length*width*height) 5800*1730*2800mm 5910x1910x2810mm 6150x1970x3000mm 7050x2430x3120mm 7050x2430x3120mm
18 Engine option 1. weifang ZH4102 2.WEICHAI HUAFENG ZH402GG41 1. weifang ZH4102. 2.WEICHAI HUAFENG R4105G57 1. luotuo YTR4108. 2. Xinchai 4105 3 . CUMMINS 4BT3.9 1. xichai 6110 2. CUMMINS 6BT5.9 1. xichai 6110 2. weichai 6105 3. CUMMINS 6BT5.9 4 DEUTZ TD226B

1.Hangzhou Advance Gear group WG180 torque converter and fix-shaft gearbox , with ZF technology 2. Single lever pilot control system makes operation easy and comfortable 3.Strengthened axles owns large bearing capacities and high reliability 4.Twin pump merging hydraulic system makes lower consumption and excellent performance 5.The coaxes flow -amplified ,hydraulic compensated steering makes operation easy and performance reliable 6.Air over hydraulic brake system ;eight caliper disc brakes
