Small Loader

Shanghai Gather Power Industry Co., Ltd.
Small Loader thumbnail-1
Small Loader photo-1
US$ 5,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
GP
Model Number:
ZL30
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name GP
Model Number ZL30
Place of Origin Shanghai, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 5910x1910x2810mm
Rated Load 3000KG
Certification CE,SGS,UL ,ISO9001
Warranty 1 YEAR
After-sales Service Provided Overseas third-party support available

Specifications

2.ISUZU weight bridge
3.Control system of clutch adopts mechanical.

1.Single lever pilot control system
2.Strengthened axles with large bearing capacities
3.Air over hydraulic brake system.
ModelZL18ZL20ZL28ZL30ZL30A
Rated weight1800KG2000KG2800KG3000KG3000KG
Rated capacity1.03m³1.3m31.6m31.7m31.7m3
Operating weight4000KG7480KG6000KG9500KG9500KG
Model of engineWeifang ZH4102weifang ZH4102luotuo YTR4108xichai 6110DEUTZ TD226B
Rated power50KW/47 KW45KW55KW85KW92KW
Rated speed2200r/min 2400rpm2400r/min2400r/min2300r/min2300r/min
Max .dump height3200/3700/4500mm2800mm3200/3500mm3020/3250mm3250mm
Max .dump reach≥930mm885mm1084mm1200mm1200mm
Min .ground clearance310mm310mm310mm380mm380mm
Wheel base2160mm2150mm2470mm2760mm2760mm
Tread1080mm1440mm1380mm1800mm1800mm
Lifting time4sTotal time:9.8sTotal time:11.3sTotal time:11sTotal time:11s
Lowering time3s
Unloading time2s
Max.breakout force32KN48.87KN70KN138KN138KN
Min.turning radius3500mm4239mm4500mm5700mm5700mm
Overall dimensions(length*width*height)5800*1730*2800mm5910x1910x2810mm6150x1970x3000mm7050x2430x3120mm7050x2430x3120mm
Engine option :1.Weifang ZH4102 2.Weichai Huafeng ZH402GG411. Weifang ZH4102. 2.Weichai Huafeng R4105G571.Luotuo YTR4108. 2.Xinchai 4105 3 . Cummins 4BT3.91. Xinchai 6110 2.Cummins 6BT5.91. Xinchai 6110 2.Weichai 6105 3.Cummins 6BT5.9 4 .Deutz TD226B
