Home > Manufacturing & Processing Machinery > Lifting Equipment > Lifting Table > 32 Meters,4WD,Telescopic Boom Lift

32 Meters,4WD,Telescopic Boom Lift

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Model Number:

GTBZ32

Contact Supplier Request Quote Chat Now

Shanghai Gather Power Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name GP

Model Number GTBZ32

Lift Mechanism Telescoping Lift

Lift Drive / Actuation Hydraulic

Rated Loading Capacity 250kgs

Max. Lifting Height 34 meters

Table Size 1.83*0.76*1.1M

Weight 18820kgs

Certification ISO&CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

360 full direction operation
Max.load capacity 250kgs
Self-adaption floating device
Overload limit and rollover protection

Productivity	GTBZ30	GTBZ32
Platform height max.	30.4M (100ft)	32M (105ft)
Working height max.	32.4M (106ft)	34M (112ft)
Horizontal reach max.	22.9M (75ft)	24.4M (80ft)
Turntable rotation	360°continuous	360°continuous
Platform rotation	160°	160°
Platform Load capacity	340kg (non-restricted)	250kg (non-restricted)
Platform Load capacity	480kg (restricted)	250kg (non-restricted)
Grade ability	42% (4wd)	40% (4wd)
Turning radius(outside)	5.57M (18ft)	5.57M (18ft)
Turning radius(inside)	2.56M (8ft)	2.56M (8ft)
Turntable tailswing	1.82M (6ft)	1.82M (6ft)
Max. Driving Speed	4.4KM/H	4.4KM/H
Driving Speed (stowed)	0~4.4km/h	0~4.4km/h
Driving Speed (extended)	0~1.1km/h	0~1.1km/h
Max allowable wind force	12.5m/s	12.5m/s
Max allowable slope	3°	3°
Max noiseon normal use	82dB(A)	82dB(A)
Max allowable side force	400N	400N
Dimensions	GTBZ30	GTBZ32
Overall length(stowed)	13M (43ft)	14.02M (46ft)
Overall width(stowed)	2.49M (8ft)	2.49M (8ft)
Overall height(stowed)	3.08M (10ft)	3.08M (10ft)
Ground clearance	0.25M (0.8ft)	0.25M (0.8ft)
Wheelbase	3.66M (12ft)	3.66M (12ft)
Overall weight	18670kg (4WD)	18820kg (4WD)
Overall weight	18670kg (4WD)	18820kg (4WD)
Platform Size (LWH)	2.440.911.1M (8ft3ft3.6ft)	1.830.761.1M(6ft 2.5ft 3.6ft)
Platform levelling	Automatic	Automatic
Tire specification	12.00-20	12.00-20
Tire type	Solid	Solid
Hydraulic tank vol.	200L	200L
Hydraulic system vol. (inc. the tank)	300L	300L
Fuel tank vol.	150L	150L
Control voltage	24V	24V
Engine	Original CumminsB3.3 80hp	Original CumminsB3.3 80hp
Drive & steer model	4WD*4WS	4WD*4WS
Standard applied: EN280, AS1418 and JG/T5100
