1.5t 6m Heavy Lifting Equipment Electric Forklift Pallet Stacker ul /ce /sgs

US$ 2,500 - 7,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Shanghai Gather Power Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Jiangsu, China

Brand Name GP

Model Number ESG115

Dimension(L*W*H) Pls Check

Certification ISO CE SGS GS

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Product Description

1.5t 6m heavy lifting equipment electric forklift pallet stacker ul /ce /sgs

Advantage

1.Configuration and performance

Electronic power steering system, light and low noise

Two-way magnetic valve, three drop speed mode

Drive unit floating bodies with patent design

AC driving system, no carbon brush, maintenance free

USA CURTIS controller

Electromagnetic, regenerative braking system

Automatic lifting limit, proximity switch, long life

2. Safety

Curve automatic deceleration devices, more safe

Stepless speed control system, safe and quiet

Controller with multiple automatic protection

Emergency reversing device/emergency brake switch

Options of high position automatic reduction device

Technology element

feature	model	unit	ESG115	ESG116
	type		Narrow legs	Narrow legs
	Mast type		2-stage STD	2-stage STD
	Load capacity	kg	1500	1600
	Load center	mm	600	600
	Wheel base	mm	1325	1325
	Operating type		Walkie/stand on	Walkie/stand on
weight	Self-weight with battery	kg	1190	1220
dimension	Wheel type		PU	PU
	The quantities of driving wheel /balance wheel /bearing wheel		1/2/4	1/2/4
	Min. height of fork above ground	mm	85	85
	Min.ground clearance	mm	30	30
	Max. lifting height	mm	3000	3000
	Fork dimension(length/ width/thickness)	mm	1150(1200)/180/60	1150(1200)/180/60
	Overall width	mm	850	850
	Outside width between legs	mm	570/600/650/685	570/600/650/685
	inside width between legs	mm	180/230/280/315	180/230/280/315
	Min. turning radius	mm	1630/1990	1630/1990
	Min.aisle width for pallets 1000*1200	mm	2160/2540	2160/2540
	Min.aisle width for pallets 800*1200	mm	2130/2520	2130/2520
performance	Travel speed, laden/unladen	Km/h	5/6	5/6
	Lift speed, laden/unladen	mm/s	95/130	95/130
	Descend speed, laden/unladen	mm/s	110/100	110/100
	Gradeability, laden/unladen	°	5/8	5/8
Electric configuration	Drive motor	kw	AC1.5	AC1.5
	Lift motor	kw	DC3.0	DC3.0
	Steering motor	kw	DC0.15	DC0.15
	Battery voltage/capacity	v/ah	24/240	24/280
	brake		Electromagnetic/regenerative	Electromagnetic/regenerative
	controller		CURTIS(USA)	CURTIS(USA)
