Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | GP |
| Model Number: | ESG115 | Dimension(L*W*H): | Pls Check | Certification: | ISO CE SGS GS |
| Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
GP brand new heavy load electric forklift pallet jack stacker with differnt height
Advantage
1.Configuration and performance
Electronic power steering system, light and low noise
Two-way magnetic valve, three drop speed mode
Drive unit floating bodies with patent design
AC driving system, no carbon brush, maintenance free
USA CURTIS controller
Electromagnetic, regenerative braking system
Automatic lifting limit, proximity switch, long life
2. Safety
Curve automatic deceleration devices, more safe
Stepless speed control system, safe and quiet
Controller with multiple automatic protection
Emergency reversing device/emergency brake switch
Options of high position automatic reduction device
Technology element
feature | model | unit | ESG115 | ESG116 |
type |
| Narrow legs | Narrow legs | |
Mast type |
| 2-stage STD | 2-stage STD | |
Load capacity | kg | 1500 | 1600 | |
Load center | mm | 600 | 600 | |
Wheel base | mm | 1325 | 1325 | |
Operating type |
| Walkie/stand on | Walkie/stand on | |
weight | Self-weight with battery | kg | 1190 | 1220 |
dimension | Wheel type |
| PU | PU |
The quantities of driving wheel /balance wheel /bearing wheel |
| 1/2/4 | 1/2/4 | |
Min. height of fork above ground | mm | 85 | 85 | |
Min.ground clearance | mm | 30 | 30 | |
Max. lifting height | mm | 3000 | 3000 | |
Fork dimension(length/ width/thickness) | mm | 1150(1200)/180/60 | 1150(1200)/180/60 | |
Overall width | mm | 850 | 850 | |
Outside width between legs | mm | 570/600/650/685 | 570/600/650/685 | |
inside width between legs | mm | 180/230/280/315 | 180/230/280/315 | |
Min. turning radius | mm | 1630/1990 | 1630/1990 | |
Min.aisle width for pallets 1000*1200 | mm | 2160/2540 | 2160/2540 | |
Min.aisle width for pallets 800*1200 | mm | 2130/2520 | 2130/2520 | |
performance | Travel speed, laden/unladen | Km/h | 5/6 | 5/6 |
Lift speed, laden/unladen | mm/s | 95/130 | 95/130 | |
Descend speed, laden/unladen | mm/s | 110/100 | 110/100 | |
Gradeability, laden/unladen | ° | 5/8 | 5/8 | |
Electric configuration | Drive motor | kw | AC1.5 | AC1.5 |
Lift motor | kw | DC3.0 | DC3.0 | |
Steering motor | kw | DC0.15 | DC0.15 | |
Battery voltage/capacity | v/ah | 24/240 | 24/280 | |
brake |
| Electromagnetic/regenerative | Electromagnetic/regenerative | |
controller |
| CURTIS(USA) | CURTIS(USA) |
We are a Chinese Manufacturer, main products cover all series of electric stackers that can be used in hospitals, clinics, store fronts, loading docks, warehouses and in many other delivery situations .
Our clients are all over the world, such as Carrefour Supermarket, the U.S. General Motors,Volkswagen, France Lafarge,Shell Petroleum,Sharp Electronic,China COSCO,Maersk Logistics and many other Fortune 500 companies.
If you have any interes ,please look me up.I will give you the best advice timely.
