Home > Transportation > Forklifts & Parts > Forklift > Parts for Stacker Reclaimer, Lifting Height 3m, ERC112
US$ 1,999 - 2,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
GP
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Radiator FG 30 T 3 for ForkliftNegotiableMOQ: 1 Unit -
22m Mast Collapsible and Removable and Insulated PlatformUS$ 5,000 - 10,000MOQ: 1 Unit
-
High Quality 80 Ton Tyre Press Forklift Assemble & Disassemble Solid Tyre MachineNegotiableMOQ: 1 Unit
-
Forklift Attachment Paper Roll Clamp With CE/ISO/GOSTUS$ 3,000 - 3,100MOQ: 1 Unit
-
Rapidly Rotating Forklift Paper Roll ClampUS$ 3,000 - 3,100MOQ: 1 Unit
Condition
New
Place of Origin
Jiangsu, China
Brand Name
GP
Model Number
ERC112
Type
Other, Battery
Power Souce
Other, Travel motor
Rated Loading Capacity
1200kg
Max. Lifting Height
3000mm
Overall Dimensions
1940*850*1465
Certification
CE/ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
parts for stacker reclaimer
1. Lifting height 3m
2. Low noise, no pollution
3.Curtis , Itaian ZAPI/SME cotroller
parts for stacker reclaimer for materials handling, Lifting height 1.6m-4.5m,with nice design.
Advantge of electric stacker
1.Conforms To The Standards Of En1726-1:1999and En1175-1:1998
2.High Stability And Flexible Operation
3.Smooth stepless speed control from CURTIS
4.Low Noise, No Pollution, And High Reliability
5. Power unit and drive wheel made in Europe
6. Large Capacity Battery Makes The Stacker Work Longer
7.Top-Quality Control System - CURTIS from USA or ZAPI / SME from Italia
FULL ELECTRIC STACKER | Model | |||||||
Item | Specification | Unit | ERC112 | ERC115 | ERC116 | ERC118 | ERC120 | |
1 | General | Rated capacity | Kg | 1200 | 1500 | 1600 | 1800 | 2000 |
2 | Load center | mm | 600 | 600 | 600 | 600 | 600 | |
3 | Drive type | Standed | ||||||
4 | Motor brake | Electromagnetic | ||||||
5 | Load distance (centerline of front axle to front face of forks) | 716 | 716 | 716 | 716 | 716 | ||
6 | Battery weight | Kg | 200 | 200 | 200 | 280 | 280 | |
7 | Self weight | Kg | 1080 | 1105 | 1130 | 1250 | 1280 | |
8 | Full Load per Axle - Driving side / bearing side | 865/215 | 885/220 | 905/225 | 1000/250 | 1025/255 | ||
9 | Empty Load per Axle - Driving side / bearing side | Kg | 970/1310 | 1110/1495 | 1095/1635 | 1300/1750 | 1400/1880 | |
10 | Dimensions | Lifting Height (standard) | mm | 3000 | ||||
11 | Fork min. ground clearance | mm | 85 | |||||
12 | Adjust width of fork (standard) | mm | 570 | |||||
13 | Fork size | mm | 60/180/1150 | |||||
14 | Minimum ground clearance | mm | 25 | |||||
15 | Overall length | mm | 1940 | 1940 | 1940 | 1970 | 1970 | |
16 | Overall width | mm | 850 | 1050 | ||||
17 | Overall height (including handle ) | mm | 1465 | 1465 | 1465 | 1465 | 1465 | |
18 | Bodywork height | mm | 845 | 845 | 845 | 845 | 845 | |
19 | Overall height mast raised | mm | 3530 | 3530 | 3530 | 3530 | 3530 | |
20 | Overall height mast lowered | mm | 2055 | 2055 | 2055 | 2055 | 2055 | |
21 | Front wheel tread | mm | 390 | 390 | 390 | 390 | 390 | |
22 | Supporting wheel tread | mm | 708 | 708 | 708 | 800 | 800 | |
23 | Minimum turning radius | mm | 1630 | 1630 | 1630 | 1630 | 1630 | |
24 | Stacking right angle aisle width | mm | 2236 | 2236 | 2236 | 2270 | 2270 | |
25 | Perfor-mance | Max. driving speed full/empty | Km/h | 5/6 | 5/6 | 5/6 | 5/5.8 | 5/5.5 |
26 | Max. lifting speed full/empty | mm/s | 110/130 | 95/130 | 90/130 | 80/120 | 80/120 | |
27 | Max. declining speed full/empty | mm/s | 120/110 | 110/100 | 110/90 | 80/90 | 80/90 | |
28 | Grade ability full/empty | % | 5/8 | 5/8 | 5/8 | 5/8 | 5/8 | |
29 | Wheel | Wheels material | Polyurethane | |||||
30 | Wheel number (front/rear) | 4/3 | ||||||
31 | Drive wheel (mm) | φ252x87 | φ252x87 | φ252x87 | φ252x87 | φ252x87 | ||
32 | Load wheel (mm) | φ80x70 | φ80x70 | φ80x70 | φ80x70 | φ80x70 | ||
33 | Balance wheel (mm) | φ150x48 | φ150x48 | φ150x48 | φ150x48 | φ150x48 | ||
34 | Wheelbase | 1295 | 1295 | 1295 | 1295 | 1295 | ||
35 | Power and Control | Travel motor | KW | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
36 | Lift motor | KW | 2.2 | 3 | 3 | 3 | 3 | |
37 | Voltage | V | 24 | 24 | 24 | 24 | 24 | |
38 | Battery capacity | Ah | 210 | 210 | 210 | 280 | 280 | |
39 | Control system | CURTIS / ZAPI / SME | ||||||
40 | Sound level at the driver's ear acc. to EN12053 | dB/(A) | 67 | |||||
