120ton Tyre Press

120ton Tyre Press thumbnail-1
120ton Tyre Press photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Tire Machine
Tire Machine Type:
Other Tire Machine
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai port or any China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tire Machine
Tire Machine Type Other Tire Machine
Place of Origin Shanghai, China
Brand Name GP
Model Number TP120
Voltage 220V/380V
Weight 1510kgs
Certification ISO&CE
Warranty one year
After-sales Service Provided Overseas service center available

Specifications

Model TP120
Maximum pressure 120 Ton,
biggest Dia.of wheel hub is 508mm
include all tools
Motors voltage adjustable

Detailed Specification of Tyre Press:
 Tyre Press / Model Unit TP80 TP120 TP160 TP200
Maximum pressure  Ton 80 120 160 200
Maximum size of wheel rims  mm 381 508 508 508
Overall length mm 1640 2090 2090 2090
Overall width mm 700 850 850 850
Overall height mm 2170 2210 2210 2210
Intensity of pressure for operation mpa 21 25 33 33
Oil cylinder stroke mm 400 400 400 400
fuel tank volume mm 30 30 30 30
Motor kw 5.5 5.5 7.5 11
Self-Weight kg 1100 1510 1610 2110
TOOLING
 Tooling for 2-piece rim tyre
Tyre Max Tyre Dimension (mm) Cage (pcs) Pusher Ring (pcs) Flange Ring (pcs)
TOOL-II 508 4 11 6

Tooling for 3-piece & 4-piece rim tyre
Tyre Max Tyre Dimension (mm) Cage (pcs) Pusher Ring (pcs) Cone (pcs) Base Plate (pcs)
TOOL-IV 508 6 6 6 3
