Home > Products > Spare parts and Attachements > 80Ton Tyre press (forklift Tire press)
80Ton Tyre press (forklift Tire press)
Negotiable
/ Unit
1 Unit(Min.Order)
- 2500 Unit / Units per Month
- ShangHai
- T/T
You May Like
Product Details
| Type: | Tire Machine | Tire Machine Type: | Other Tire Machine | Place of Origin: | Shanghai, China |
| Brand Name: | GP | Model Number: | TP80,TP120,TP160,TP200 |
Product Description
Specifications
1. high quality2. competitive price
| Detailed Specification of Tyre Press: | |||||
| Tyre Press / Model | Unit | TP80 | TP120 | TP160 | TP200 |
| Maximum pressure | Ton | 80 | 120 | 160 | 200 |
| Maximum size of wheel rims | mm | 381 | 508 | 508 | 508 |
| Overall length | mm | 1640 | 2090 | 2090 | 2090 |
| Overall width | mm | 700 | 850 | 850 | 850 |
| Overall height | mm | 2170 | 2210 | 2210 | 2210 |
| Intensity of pressure for operation | mpa | 21 | 25 | 33 | 33 |
| Oil cylinder stroke | mm | 400 | 400 | 400 | 400 |
| fuel tank volume | mm | 30 | 30 | 30 | 30 |
| Motor | kw | 5.5 | 5.5 | 7.5 | 11 |
| Self-Weight | kg | 1100 | 1510 | 1610 | 2110 |
| TOOLING | |||||
| Tooling for 2-piece rim tyre | |||||
| Tyre | Max Tyre Dimension (mm) | Cage (pcs) | Pusher Ring (pcs) | Flange Ring (pcs) | |
| TOOL-II | 508 | 4 | 11 | 6 | |
| Tooling for 3-piece & 4-piece rim tyre | |||||
| Tyre | Max Tyre Dimension (mm) | Cage (pcs) | Pusher Ring (pcs) | Cone (pcs) | Base Plate (pcs) |
| TOOL-IV | 508 | 6 | 6 | 6 | 3 |
