2-3.5Ton LPG Forklifts for Factory Use

2-3.5Ton LPG Forklifts for Factory Use thumbnail-1
2-3.5Ton LPG Forklifts for Factory Use photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number CPQ(Y)D20-35
Type Powered Pallet Truck
Power Souce Gasoline Engine
Rated Loading Capacity 2500kg
Max. Lifting Height 3000mm
Min. Lifting Height 0mm
Fork Length 1070mm
Fork Width 120mm
Overall Dimensions 2580*1150*2060mm
Certification ISO&CE
After-sales Service Provided Overseas service center available

Specifications

1)TCM technology.
2)Mitsubishi 4G64 gasoline engine.
3)Automatic transmission.
4)IMPCO converter

General   Manufacturer   SHANGHAI GP
1 Model   CPQ(Y)D20 CPQ(Y)D25 CPQ(Y)D30 CPQ(Y)D35
2 Rated capacity kg 2000 2500 3000 3500
3 Load center mm 500
4 Gearbox change speed type   Hydraulic/ Mechanical
5 Power type   Gasoline / LPG
6 Tire type Front/ Rear   Pneumatic
7 (X=)Wheels Front/ Rear   2/2
Dimensions 8 Lift height mm 3000
9 Free lift height mm 140 145
10 Fork size L*W*T mm 1070x120x40 1070x120x40 1070x125x45 1070x130x45
11 Mast tilt angle /Fwd/Bwd deg 6/12
12 () Overall length (without fork) mm 2510 2580 2720 2775
13 Overall width mm 1150 1225
14 () Mast height fork lowered mm 2050 2080 2230
15 Overall height fork raised mm 4040 4272
16 Overall height (overhead guard) mm 2060 2090
17 () Turning radius (outside) mm 2170 2240 2460 2540
18 Load distance (centerline of front axle to front face of forks mm 484 489 494 500
19 Wheel base mm 1650 1700
20 Tread Front mm 970 1000
21 Rear mm 970
22 Min. Under-clearance (full load / no load ) () Bottom of mast mm 85/105 110/135
23 Bottom of frame mm 115/120 135/140
Performance 24 Speed Travel speed With load km/h 17 18
25 Without load km/h 19 19
26 Lifting speed With load mm/sec 470 430 400
27 Without load mm/sec 600 500 450
28 Max. Drawbar pull With/ without load kg 1250/850 1250/850 1100/1000 1304/1190
29 1650/850 1650/850 1350/1000 1696/1190
30 Max.Gradeability With/ without load % (fan) 20/20 17/18 15/18 15/18
21/22 18/19 19/20 15/18
Weight 31 Self weight kg 3550 3880 4380 4750
32 Weight distribution With load Front kg 4730 5480 6455 7320
33 Rear kg 590 700 825 930
34 Without load Front kg 1520 1465 1720 2040
35 Rear kg 1800 2215 2560 2710
Tyre 36 Tyre Size Front   7.00-12-12PR 28x9-15-14PR
37 Rear   6.00-9-10PR 6.50-10-10PR
Brake 38 Brake Service   - Hydraulic-Foot pedal
39 Parking   - Mechanical-Hand lever
Transmission 40 Battery Voltage / Capacity V/AH 12/100
41 Internal combustion engine Model for option   NISSAN / MITSUBISHI / GQ- 4Y
42 Transmission Type   / Hydraulic/Mechanical
43 shift (/ Fwd/Rvs)   1/1 (2/2)
  44 Work pressure Mpa 17.5
