Three Wheel Balance Weight Battery Forklift Truck

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Anhui, China

Brand Name:

Shanghai Gather Power Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any china port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Anhui, China

Brand Name GP

Model Number TK-A

Type Other, battery forklift

Power Souce DC Motor

Rated Loading Capacity 1000kg-1500kg

Max. Lifting Height 4500

Min. Lifting Height 3000

Specifications

battery forklift with small turning radius,low price

Electric Forklift Truck With 3 Wheel

Electric Forklift Truck With 3 Wheel :

Product Information:

Model	TK10A-30	TK15A-30
Load capacity kg	1000	1500
Load center mm	500	500
Lifting height mm	3000	3000
Fork size	92010035	92010035
Mast tilt (forth/back)	2o/5o	2o/5o
Mast height mm	2155	2155
Max lift mast height mm	3738	3738
Overhead guard height mm	1980	1965
Height between the seat and the ground mm	930	920
Overall length(include forks) mm	2320	2420
Overall width mm	850	960
Wheelbase (adjustable) mm	869-949	947-1027
Gap between the truck and the ground mm	90	90
Turning radius mm	1167	1236
Steering type	Hydraulic	Hydraulic
Driving speed(load/unload) km/h	6.3/8.3	6.0/8.0
Gradeability %	8	8
Service brake	Hydraulic	Hydraulic
Parking brake	mechanical	mechanical
Battery 24V	D-360	D-420
Weight(including battery) kg	2278	2485
Driving motor kw	2.5	2.5
Lifting motor kw	3	3
Front wheel size *2pc	305×127×203.2	305×140×203.2
Rear wheel size *1pc	267×140	267×140
