1 Ton Electric Forklift With Side Shift, 3 Stage Mast Made in China

Shanghai Gather Power Industry Co., Ltd.

US$ 100 - 9,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name GP

Model Number CPD10

Type Powered Pallet Truck

Power Souce DC Motor

Rated Loading Capacity 1000kg

Max. Lifting Height 300mm

Min. Lifting Height 0mm

Fork Length 920mm

Fork Width 100mm

Overall Dimensions 2056*1090*2162mm

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

DC powered, 4 wheel options
1.5/2/2.5/3/3 tons
Imported Electronic Control, Seal & Bearing
CE, ISO audit Manufaturer

Specifications:

Characteristics
1	4-wheel DC Power Pneumatic Tire Electric Forklift				CPD10	CPD15
2	Capacity	at rated load center		kg	1000	1500
		at load center - distance		mm	500
3	Power	diesel, Gasoline / LPG, electric			electric
4	Tire Type	solid, pneumatic			pneumatic
5	Wheels (x = drive)		number front / rear		2x/2
Dimensions
6	Lift Height with standard two-stage mast (VM)			mm	3000
7	Free Lift Height			mm	162
8	Fork size		LengthWidthThickness	mm	920x100x40
9	Fork spacing (Min./Max.)		out-to-out	mm	200/968
10	Mast tilt angle		Forward / Backward	deg	6/12
11	Overall dimensions	length (to fork face)		mm	2056
		width (standard)		mm	1090
		height	with lowered mast	mm	1995
			with extended mast	mm	4042
			to top of overhead guard	mm	2162
12	Turning radius (outside)			mm	1820
13	Load distance (centerline of front axle to front face of forks)			mm	429
14	Minimum Aisle -90° stack (Add load length and clearance)			mm	3370
Performance
15	Speeds	Travel speed	loaded	km/h	11.5	11
16			empty	km/h	13.5	13
17		Lifting speed	loaded	mm/sec	300	285
18			empty	mm/sec	400	390
19	Gradeability		loaded/empty	%	15
Weight
20	empty	with minimum weight battery		Kg	2900	3120
Chassis
21	Tyre Size	Front, standard pnuematic tires			6.5-10-10PR
22		Rear, standard pnuematic tires			5.00-8-8PR
23	Wheel base			mm	1250
24	Tread width		Front	mm	890
			Rear	mm	920
25	Min. Under-clearance (full load / no load )		at lowest point at mast	mm	95/110
26			at center of wheelbase	mm	95/105
Powertrain
27	Battery	Voltage		V	48
28		Capacity		AH	400/440/480
29	Electric motor	Drive motor output		kw/rpm	5.3/1700
30		Hydraulic motor output		kw/rpm	8.2/1600
31	controller			USA CURTIS electric controller /American GE separate excitation electric controller
