2.5Ton Electric Forklift Truck

2.5Ton Electric Forklift Truck thumbnail-1
2.5Ton Electric Forklift Truck photo-1
US$ 5,000 - 13,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number CPD25
Type Other
Power Souce AC Motor
Certification ISO9001
After-sales Service Provided Overseas third-party support available
Product Description







Characteristics
1 4-wheel AC Power Pneumatic
Tire Electric Forklift		   CPD20 CPD25 CPD30 CPD35
2 Capacity at rated load center kg 1500 2000 2500 3000
at
load center - distance		 mm 500
3 Power diesel,
Gasoline / LPG, electric		   electric
4 Tire Type solid, pneumatic   pneumatic
5 Wheels (x = drive) number front / rear   2x/2
Dimensions
6 Lift
Height with standard two-stage mast
(VM)		 mm 3000
7 Free Lift Height mm 2x/2 140 140 145
8 Fork size Length*Width*Thickness mm 920x100x40 1070x120x40 1070x120x45 1070x125x45
9 Fork spacing (Min./Max.) out-to-out mm 200/968 240/1040 240/1040 250/1100
10 Mast tilt angle Forward /
Backward		 deg 6/12 6/10 6/10 6/10
11 Overall


dimensions		 length (to fork face) mm 2056 2349 2381 2481
width (standard) mm 1090 1265 1265 1265
height with lowered mast mm 1995 2040 2040 2040
with extended mast mm 4042 4240 4240 4273
to top of overhead guard mm 2162 2125 2125 2125
12 Turning
radius (outside)		 mm 1820 2050 2100 2230
13 Load distance (centerline of front axle to front face of forks) mm 429 459 464 454
Performance
14 Speeds Travel speed loaded km/h 13 12 12 12
15 empty km/h 15 14 14 14.5
16 Lifting
speed		 loaded mm/sec 300 310 300 280
17 empty mm/sec 400 420 420 420
18 Gradeability loaded/empty % 15 10 10 10
Weight
19 empty with minimum weight battery   Kg 3120 4160 4360 4850
Chassis
20 Tyre Size Front, standard pnuematic
tires		   6.5-10-10PR 23x9-10-16PR 23x9-10-16PR 23x9-10
21 Rear, standard pnuematic
tires		   5.00-8-8PR 18x7-8-14PR 18x7-8-14PR 18x7-8
22 Wheel
base		 mm 1250 1500 1500 1630
23 Tread width Front mm 890 1040 1040 1040
Rear mm 920 950 950 980
24 Min. Under-clearance (full load / no load ) at lowest point at
mast		 mm 95/110 85/105 85/105 85/105
25 at center of
wheelbase		 mm 95/105 120/140 120/140 120/140
Powertrain
26 Battery Voltage V 48 48 48 80
27 Capacity AH 400/440/480 630/700 630/700 500/600
28 Electric motor Drive motor output kw/rpm 8/1600 8/1300 8/1300 13/1500
29 Hydraulic motor output kw/rpm 10/2450 15/2200 15/2200 22/2100
30 controller   Italian SME AC controller

 2.5Ton Electric Forklift Truck



Packaging & Shipping

 Company Introduction



2.5Ton Electric Forklift Truck

    Shanghai Gather Power Industry Co.,Ltd (shanghai gather power), was registered in 2006 in Shanghai, China, a major industrial logistics equipment manufacturer and supplier of professional products, the main production and operation of three series of products: 1 t -2.5 t full electric stacker, 1 t -3 t full electric pallet trucks, 1 t -2.5 t Reach forklift and other electric storage equipment; 6 meters - 30 meters series of aerial work platforms; 25 tons -45 tons of container crane and so on.

Company has three bases: Shanghai Fengxian production base; Pudong Zone International Trade Company; Lu'an production base - Anhui Vmax Machinery Co., Ltd.

After nearly seven years of continuous development, the company has entered a rapid healthy development. The company has a total of over 40,000 square meters of production space, with a large number of such large-scale CNC flame plasma cutting machine, high-precision machining centers, CNC milling machine, large hydraulic machines, systems integrated coating equipment, as well as the international advanced assembly products performance test line, precision testing equipment, vehicle testing facilities to strengthen inspection and testing systems, which are fully guaranteed product standards and quality.

permarket, Sharp Electronics, China COSCO, Maersk Logistics and many other Fortune 500 companies.
