Electric stacker, full electric stacker, with electric motor, a battery energy industrial handling vehicles, refers to pieces of pallet for loading and unloading, wheeled carrying vehicles piled high, stacking and short distance transportation. The international organization for standardization ISO/TC110 known as industrial vehicles. Electric stacker includes all electric forklift trucks, semi electric stacker, forward type stacker, forward type full electric stacker, forward type stacker, walking counterbalanced forklift trucks.
characteristic |
model |
|
ESC107 |
ESC110 |
ESC112 |
ESC115 |
operating type |
|
Walk |
Stand on/ walk |
Stand on/ walk |
Stand on/ walk |
|
power source |
|
battery |
battery |
battery |
battery |
|
load capacity |
Kg |
700 |
1000 |
1200 |
1500 |
|
|
Size
|
load center |
mm |
500 |
500 |
500 |
500 |
wheel type |
|
PU |
PU |
PU |
PU |
|
service weight |
Kg |
1247 |
1342 |
1582 |
1762 |
|
|
Wheel dimension (driving wheel/ balance wheel/ bearing wheel) |
mm |
|
φ320x70 / φ130x55 / φ210x85 |
|
||
wheel base |
mm |
825 |
1164 |
1184 |
1184 |
|
|
Wheel quantity (driving wheel/ balance wheel/ bearing wheel) |
pcs |
1-2-2 |
1-2-2 |
1-2-2 |
1-2-2 |
|
Operate handle (highest/lowest) |
mm |
1413/1050 |
1413/1050 |
1413/1050 |
1413/1050 |
|
Overall length (pedal away/pedal on) |
mm |
2020 |
2679/3099 |
2699/3119 |
2699/3119 |
|
overall width |
|
827 |
856 |
856 |
856 |
|
Fork dimension (thickness/length/ width) |
mm |
35/100/920 |
35/100/920 |
35/100/920 |
35/100/920 |
|
Fork spacing |
mm |
555 |
200-1040 |
200-1040 |
200-1040 |
|
Outside width between forks |
|
|
|
|
|
|
min.ground clearance |
mm |
63 |
63 |
63 |
63 |
|
fork lift height |
mm |
2000 |
3000 |
3000 |
3000 |
|
m in.turning radius |
mm |
1060 |
1403 |
1423 |
1423 |
|
Min.aisle width for pallets |
mm |
2310 |
3510 |
3510 |
3510 |
|
Mast tilt angle(F/R) |
° |
- |
3/6 |
3/6 |
3/6 |
|
Front overhang |
mm |
175 |
175 |
175 |
175 |
|
Gradeability (laden/unladen) |
% |
8/10 |
8/10 |
6/8 |
6/8 |
|
|
Travelspeed (laden/unladen) |
Km/h |
5.5/6 |
5.5/6 |
5.5/6 |
5.5/6 |
|
performance |
Lift speed (laden/unladen) |
mm/s |
75/110 |
75/110 |
75/110 |
75/110 |
|
Lowering speed (laden/unladen) |
mm/s |
200/100 |
200/100 |
200/100 |
200/100 |
|
Brake type |
|
electromagnetic |
electromagnetic |
electromagnetic |
electromagnetic |
|
drive motor (AC) |
Kw |
1.5 |
1.5 |
1.5 |
1.5 |
|
lift motor(DC) |
Kw |
2.2 |
2.2 |
2.2 |
2.2 |
|
steering motor(DC) |
Kw |
0.165 |
0.165 |
0.165 |
0.165 |
|
battery voltage |
V |
24 |
24 |
24 |
24 |
|
battery capacity |
Ah |
160 |
180 |
210 |
280 |
|
controller |
|
CURTIS |
CURTIS |
CURTIS |
CURTIS |
|
Shanghai Gather Power Industry Co.,Ltd (shanghai gather power), was registered in 2006 in Shanghai, China, a major industrial logistics equipment manufacturer and supplier of professional products, the main production and operation of three series of products: 1 t -2.5 t full electric stacker, 1 t -3 t full electric pallet trucks, 1 t -2.5 t Reach forklift and other electric storage equipment; 6 meters - 30 meters series of aerial work platforms; 25 tons -45 tons of container crane and so on.
Company has three bases: Shanghai Fengxian production base; Pudong Zone International Trade Company; Lu'an production base - Anhui Vmax Machinery Co., Ltd.
After nearly seven years of continuous development, the company has entered a rapid healthy development. The company has a total of over 40,000 square meters of production space, with a large number of such large-scale CNC flame plasma cutting machine, high-precision machining centers, CNC milling machine, large hydraulic machines, systems integrated coating equipment, as well as the international advanced assembly products performance test line, precision testing equipment, vehicle testing facilities to strengthen inspection and testing systems, which are fully guaranteed product standards and quality.
Company has been adhering to the "green technology as the driving force, continue to create value for customers," business philosophy, the company has been a steady stream of products exported to Germany, France, Spain, USA, Brazil, Chile, Saudi Arabia, South Africa, Australia and other world more than 70 countries and more than 20 domestic provinces, the current good performance of the company's sales and 30% per year rate of rapid growth. Peng on sea-based clients all over the world, such as the U.S. General Motors, Volkswagen, France, Lafarge, Shell Petroleum, China Petrochemical, Carrefour supermarket, Sharp Electronics, China COSCO, Maersk Logistics and many other Fortune 500 companies.
The company attaches great importance to new product development, has a group of dedicated, experienced and dynamic professional R & D team, according to the law of development of the industry can continue to introduce and improve the market needs new products to meet customers' actual needs. The company has passed ISO9000 , CE, SGS, UL and a series of international quality management system certification. The company has a sound service system, customer interests, to long-term cooperation with customers for the purpose of agencies around the world have established a good strategic and cooperative relations, and fully guarantee our products fast market expansion.
