2016 Hot Sale Double Mast Capacity 1ton 1.5ton 2ton Semi Electric Stacker
2016 Hot Sale Double Mast Capacity 1ton 1.5ton 2ton Semi electric Stacker
Feature:
1) Manual ahead, Electric rise
2) Load capacity;1.0/1.5/2.0 ton
3) Lift height;1.6m
4) Overall Height 2.06m
| Model | JK8446 | JK8447 | JK8448 | |
| Capacity(Q) | kg | 1000 | 1500 | 2000 |
| Load center(C) | mm | 400 | ||
| Max fork height(H) | mm | 1600 | ||
| Fork length(L) | mm | 1000 | ||
| Fork outer width(E) | mm | 300~850 (Adjustable ) | ||
| Min turning radius | mm | 1350 | ||
| Wheelbase(Y) | mm | 1180 | ||
| Front wheel cardinal distance(X) | mm | 322 | ||
| Load wheel-diameter | mm | Φ80×60 | ||
| Steering Rollers-diameter | mm | Φ180×50 | ||
| Lifting Motor? | v/kw | 12/1.5~1.6 | ||
| Battery? | v/Ah | 12/120 | 12/150 | |
| Charger | v/A | 12/15 | ||
| Overall length(A) | mm | 1670 | ||
| Overall width(B) | mm | 820 | ||
| Overall height(H1) | mm | 2060 | ||
| Net Weight | kg | 340 | 362 | 388 |
Shenchuan (Shanghai) Heavy Industrial Machinery Co., Ltd. was established in May 2003 in Shanghai. Over the past 10 years, we have been always adhering to the idea of “all service to meet customers’ needs”, breaking through technology, manufacturing the finest products, improving service with our globalization vision.
We have developed a variety of international advanced products joint with world-renowned industrial equipment manufacturers, such as: ABB, ZF, BOSCH, CAT, TEREX, and a variety of sophisticated products with independent intellectual property patents together with well-known Chinese universities in the area of machinery, electronics, physical mechanics etc.
Shenchuan Heavy Industrial has become one-stop storage and logistics solution leader and the most powerful supplier of material handling integrated systems. We have five divisions: Logistics Systems Division (sub-brand JEAKUE); Engineering Machinery Division (sub-brand JEADE); Agricultural Machinery Division (sub-brands JEATN); Construction Machinery Division (sub-brands JEADA); Mining Machinery Division (sub-brand JEAYO).
We will provide comprehensive and multidimensional supply chain service for global customers with our most optimized scheme, best quality products, most attentive service and most competitive price, to reduce the maximum supply chain cost for customers and increase the production efficiency.
Shenchuan(Shanghai) Heavy Industrial Machinery Co.,Ltd
Contact: Ada Chen
Office Tel: +86-551-62844001
Mobile/whatsapp No.:+86 13651636408
