Textile factory use Fabric special purpose Electric Tow Tractor
Item No. |
JK8180 |
||
Charactiristics |
Electric source |
|
Electric |
Operation type |
|
Walking type |
|
Lifting rated loading weight |
Kg |
≤1000 |
|
Drag and drop rated loading weight |
Kg |
≤3000 |
|
Rated loading wewight of pull rob on hook |
kg |
97.6 |
|
Focal distance |
mm |
112 |
|
Wheel base(y) |
mm |
999 |
|
Weight (excluding battery) |
kg |
435 |
|
Wheels |
Tyre |
|
polyurethane |
Driving end of wheel |
mm |
Φ230x75 |
|
Loading end of wheel |
mm |
Φ150x60 |
|
Size of balance wheel |
mm |
Φ100x50 |
|
Qty of wheel (x= driving wheel), driving end/loading end |
|
1x-2/2 |
|
Surface width of the driving end |
mm |
400 |
|
Surface width of the loading end |
mm |
568 |
|
Size |
Whole height |
mm |
1400 |
Lifting height |
mm |
378 |
|
Handle height at the driving position (max/min) |
mm |
1350/800 |
|
Whole height |
mm |
1227 |
|
Length to pallet fork |
mm |
565 |
|
Whole width |
mm |
850 |
|
Min ground clearance |
mm |
70 |
|
Turning radius |
mm |
1200 |
|
Performance |
Running speed(full load/no load) |
Kw/h |
5.2/6 |
Lifting speed(full load/no load) |
mm/s |
40/50 |
|
Declining speed(full load/no load) |
mm/s |
50/40 |
|
Max gradeability(full load/no load) |
% |
8/15 |
|
Service brake |
|
Electromagnetic type |
|
Driving |
Driving motor watt |
kw |
1.1 |
Lifting motor watt |
kw |
2.2 |
|
Battery, voltage/capacitance |
V/Ah |
24/210 |
|
Weight of battery |
kg |
195 |
|
Others |
Driving control type |
|
Field effect tube control |
Noise class to operator |
dB(A) |
<70 |
|
