ZZ32573647A1Sinotruk 6*4 Dumper Trucks

ZZ32573647A1Sinotruk 6*4 Dumper Trucks photo-1
ZZ32573647A1Sinotruk 6*4 Dumper Trucks photo-2
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Drive Wheel:
6x4
Capacity (Load):
21 - 30t
Horsepower:
251 - 350hp
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Drive Wheel 6x4
Capacity (Load) 21 - 30t
Horsepower 251 - 350hp
Condition New
Transmission Type Manual
Emission Standard Euro 3
Fuel Type Diesel
Engine Capacity 6 - 8L
Gross Vehicle Weight 25000
Brand Name sinotruck howo
Model Number ZZ32573647A1
Dimensions (L x W x H) (mm) 8214*2496*3450 mm

ZZ32573647A1Sinotruk 6*4 Dumper Trucks  ( ZZ32573647A1 )





2013 China Brand New 10-wheel sinotruck howo dump truck tipper truck 6x4 ZZ32573647A1  for sale

1.Specification of sinotruck howo 10 wheel dumper truck tipper truck 6x4 ZZ32573647A1  6x4:

Vehicle Model ZZ32573647A1
Cab HW76 Cab,single sleeper. Can bus and VOD dashboard.4-point support fully floating suspension and shock absorbers.
Engine Engine model: WD615.47, Euro II emission standard,6-cylinder in-line with water cooling, turbo-charging and intercooling
Maximum output: 371 hp (273 Kw) at 2200 rpm
Maximum torque: 1470 Nm at 1300-1600 rpm
Number of cylinder: 6
Displacement: 9.726 I
Specific fuel consumption: 198 g/kWh
Driving Axle HC16,casting steel axle with 13 tons rated loading capacity
Front Axle HF9 HOWO new off road 9T front axle,drum brake
Steering ZF8098,hydraulic steering with power assistance
Tires 12.00R20 bias tire with one spare tyre
Carriage 5200*2300*1400(16.744 cbm)                                           Thickness(mm): Floor:8  Side:6                                              China Ventral lifting.
Brakes Service brake: dual circuit compressed air brake Parking brake                                                                        emergency brake: spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Performance Max. speed (km/h): 75                                                             Curb.mass:12290kg                                                                   Total mass: 25000kg                                                             Front/rear overhang (mm): 1500/1670                          Approach/ departure angle: 16/26
Overall sizes (mm) 8214*2496*3450
