SINOTRUK 6X4 Mining Dump Truck for Sale

Name: SINOTRUK 6X4 Mining Dump Truck for Sale
Brand: sinotruck howo
SKU: 140723582
Availability: InStock

Evangel Industrial (Shanghai) Co., Ltd.

US$ 10,000 - 50,000 MOQ: 1 Set

Key Specifications

Drive Wheel:

6x4

Capacity (Load):

21 - 30t

Horsepower:

251 - 350hp

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 6x4

Capacity (Load) 21 - 30t

Horsepower 251 - 350hp

Condition New

Transmission Type Manual

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity 6 - 8L

Gross Vehicle Weight 25000

Brand Name sinotruck howo

Model Number ZZ3257N3647A

Dimensions (L x W x H) (mm) 5400x2300x1400 mm

Howo 6x4 dump truck for sale

Truck Model				ZZ3257N3647A (LHD)
Truck Brand				SINOTRUK –HOWO
Dimension(Lx W xH)(unloaded)				8214x2496x3386
Cargo body size (LWH, mm)				5400x2300x1400
Cargo body thickness(mm)				bottom:8mm, side:6mm,
Lift type of Carriage				Ventral lifting
Approaching angle/Departure angle(°)				19/26
Overhang(front/rear) (mm)				1500/1739
Wheel base (mm)			3625+1350
Max speed(km/h)			75
Curb weight(kg)			12290
Loading Weight(kg)			30000
Fuel tanker capacity			300L with locking fuel cap
Fuel consumption(L/100km)			32
Clutch			Single-plate dry clutch Φ420mm
Engine Model (Steyr technology, made in China)	Model		WD615.47,4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and intercooling
	Horse Power, max(kw/rpm)		336HP,247/2200
	Emission Standard		EURO II
Transmission		Model	HW 19710,10 forwards and 2 reverse
Brake system		Service brake	Dual circuit compressed air brake
		Parking brake	spring energy, compressed air operating on rear wheels
		Auxiliary brake	Engine exhaust brake
Steering system		Model	ZF8098 hydraulic steering with power assistance
Front axle		HF9 , Steering with double T-cross section beam Loading capacity:9000KG
Rear axle		HC16, Casting axle housing, central double reduction with differential locks between axles and wheels
Color		Optional
Tire		12.00-20 11 pieces
