SINOTRUK 6X4 mining dump truck for sale
- 100 Set / Sets per Month
- Shanghai
- T/T L/C
Product Details
Drive Wheel: | 6x4 | Capacity (Load): | 21 - 30t | Horsepower: | 251 - 350hp |
Condition: | New | Transmission Type: | Manual | Emission Standard: | Euro 3 |
Fuel Type: | Diesel | Engine Capacity: | 6 - 8L | Gross Vehicle Weight: | 25000 |
Brand Name: | sinotruck howo | Model Number: | ZZ3257N3647A | Dimensions (L x W x H) (mm): | 5400x2300x1400 mm |
Product Description
Howo 6x4 dump truck for sale
Truck Model | ZZ3257N3647A (LHD) | ||||
Truck Brand | SINOTRUK –HOWO | ||||
Dimension(Lx W xH)(unloaded) | 8214x2496x3386 | ||||
Cargo body size (L*W*H, mm) | 5400x2300x1400 | ||||
Cargo body thickness(mm) | bottom:8mm, side:6mm, | ||||
Lift type of Carriage | Ventral lifting | ||||
Approaching angle/Departure angle(°) | 19/26 | ||||
Overhang(front/rear) (mm) | 1500/1739 | ||||
Wheel base (mm) | 3625+1350 | ||||
Max speed(km/h) | 75 | ||||
Curb weight(kg) | 12290 | ||||
Loading Weight(kg) | 30000 | ||||
Fuel tanker capacity | 300L with locking fuel cap | ||||
Fuel consumption(L/100km) | 32 | ||||
Clutch | Single-plate dry clutch Φ420mm | ||||
Engine Model (Steyr technology, made in China) | Model | WD615.47,4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and intercooling | |||
Horse Power, max(kw/rpm) | 336HP,247/2200 | ||||
Emission Standard | EURO II | ||||
Transmission | Model | HW 19710,10 forwards and 2 reverse | |||
Brake system
| Service brake | Dual circuit compressed air brake | |||
Parking brake | spring energy, compressed air operating on rear wheels
| ||||
Auxiliary brake | Engine exhaust brake
| ||||
Steering system
| Model | ZF8098 hydraulic steering with power assistance | |||
Front axle | HF9 , Steering with double T-cross section beam Loading capacity:9000KG | ||||
Rear axle | HC16, Casting axle housing, central double reduction with differential locks between axles and wheels | ||||
Color | Optional | ||||
Tire | 12.00-20 11 pieces | ||||
|
