Original heli forklift parts
USD $10,000 - $100,000
/ Set
1 Set(Min.Order)
- 200 Set / Sets per Month
- Shanghai
- T/T Credit Card
You May Like
Product Details
Condition: | New | Place of Origin: | Anhui, China | Brand Name: | Heli |
Model Number: | CPCD30 | Type: | Manual Pallet Truck | Power Souce: | Diesel Engine |
Rated Loading Capacity: | 3 tons | Max. Lifting Height: | 3-6M | Min. Lifting Height: | 1.5M |
Fork Length: | 1220mm | Certification: | ISO,CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Original heli forklift parts
1.longer time warranty: one year,
2.package:sea protecting package with film not nude wether by container or not.
3.quality is strong with good steel body frame, brand component, technology is mature.
4.suitable design that the length size of forklift is longer because of the suitable driving space
5.lower price compare the same machines
6.service is satisfied with our after-sales team and engineering team
SPECIFICATION | |||
Model | CPCD30 | ||
Power type | Diesel | ||
Rated capacity | kg | 3000 | |
Load center | mm | 500 | |
Lift height | mm | 4500 | |
Free lift height | mm | 145 | |
Fork size | mm | 1220×125×45 | |
Mast tilt angle | deg | 6/12 | |
Front overhang | mm | 482 | |
Overall | Length to face of forklift | mm | 2695 |
Overall width | mm | 1225 | |
Mast lowerd height | mm | 2070 | |
Mast extended height | mm | 4250 | |
Overhead guard height | mm | 2090 | |
Turning radius | mm | 2420 | |
Min.right angle aisle width | mm | 2885 | |
Speeds | Drive speeds | km/h | 18/19.5 |
Lifting speeds | mm/s | 470/520 | |
Lowering speeds | mm/s | ≤600 | |
Max.grade ability | % | 15 | |
Total weight | kg | 4350 | |
Tires | Frot | 28*9-12PR | |
Rear | 6.5-10-10PR | ||
Wheeslbase | mm | 1700 | |
Tread | Front | mm | 1000 |
Rear | mm | 970 | |
Hold under mast | mm | 110 | |
Engine | Model | Xinchang 490BPG | |
Rated output | kw/rpm | 37/2650 | |
Rated torque | N.m/rpm | 148/2000 | |
No.of cylinder | 4 | ||
Displacement | L | 2.54 | |
Fuel tank capacity | L | 52 |
