90t Good Price Pipe Layer PIPELINEMAN PMG90

Name: 90t Good Price Pipe Layer PIPELINEMAN PMG90
Brand: PIPELINEMAN
SKU: 140723126
Availability: InStock

Evangel Industrial (Shanghai) Co., Ltd.

US$ 52,000 - 250,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

PIPELINEMAN

Model Number:

PMG90

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name PIPELINEMAN

Model Number PMG90

After-sales Service Provided Engineers available to service machinery overseas

90t good price pipe layer PIPELINEMAN PMG90

oil pipe layer sell factory good price email:martin at

Pipe layer Shantui sell mobile:+86-18202126581

PMG20 Pipelayer is the equipment specially designed for various pipe laying operations by Pipelineman.

A special chassis, Model T140-2, normally used by bulldozers, together with a wet clutch and brake system, are used to improve the operational life and reliability of the equipment.
The hydraulic crane boom is installed with a location snubber to avoid bending damages of the boom. The over-rolling limiter can protect the equipment from possible damages on hook and slings. The emergency off-loading device may ensure the safe operations of the operator once over-loading and equipment tilting occurs.
The direct-injection turban-drive supercharged diesel engine, Model WD615, is used to ensure high operational reliability and long operational life.
A hydraulically-operated mechanical transmission system, Model T140-2, is used to operate at 98% in transmission efficiency.
The loading system uses full-hydraulic transmission for stable transmission and unique micro-performance controls.
The operational system, including gear-shifting, turning and braking system, uses flexible-shaft and rod for direct pushing and pulling to ensure convenient and reliable driving operations. The loading system is equipped with universal hydraulic lever for easy control operations in boom extension and hook loading, whereas the counterweight stretching is controlled by a hydraulic lever.

Description				Specifications
Model				PMG20
Max. Loading Capacity, ton				21
Max. Loading Torque, kNm				262.5(21×1.25)
Gross Weight, ton				23.6
Dimensions (L x W x H), mm				5540×3008×3055
Mass Weight for Transportation, tons				20
Average Ground Pressure, kPa				80
Min. Off-ground Clearance, mm				355
Max. Grade-up Slope, °				25
Work Environment				Temperature:-20⁰C~+50⁰C; Elevation: less than 3000 m
Engine	Model			Weichai WD615
	Rated Power, kW			128
	Rated Rotation Speed, rpm			1850
Driving System	Chassis			XG T140-2
	Control Mode			Control Lever
	Theoretical Speed		Forward, 4 gears, km/h	2.5/3.55/5.68/7.53
			Reverse, 3 gears, km/h	3.53/4.96/7.94
	On-ground Track Length, mm			2570
	Track Width, mm			560
	Number of Track Rollers			6×2(one side: 4×2; two sides: 2×2
Loading System	Luffing Mode			Sling
	Control Mode			Hydraulically-Controlled Lever
	Boom	Boom Frame Length, mm		6000
		Max. Lifting Height, mm		5000
	Boom Luffing Angle			0~85⁰
	Hook Speed, 6 times, m/min			0~11
	Luffing Time, s			17
