Good Performance Diesel Engine 5 Ton All Terrain Forklift CPCD50

US$ 25,000 - 27,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

YTO

Evangel Industrial (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name YTO

Model Number CPCD50

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 5000kg

Max. Lifting Height 3000mm

Min. Lifting Height 3000mm

Fork Length 1220mm

Fork Width 150mm

Overall Dimensions 2845*1480*4270

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

Good performance diesel engine 5 ton all terrain forklift CPCD50

Product Description

Specifications:Good performance diesel engine 5 ton all terrain forklift CPCD50

YTO Engine(74.9kw/2400rpm) ,

hydraulic transmission,

pneumatic tyres,4WD,

fork length: 1220mm,

rated load: 5000kg,

Lift height: 3000mm

Speciality parameter	Model				Unit	CPCD50
	Power type					Diesel
	Rated capacity				kg	5000
	Load center			d	mm	600
	Lift height			h2	mm	3000
	Mast tilt angle (forward/backward)			α/β	Deg	6/12
	Wheel-base			L4	mm	2560
	Tread(front/rear)			b4/b5	mm	1760/1760
Performance parameter	Travel brake					Hydraulic-Foot pedal
	Parking brake					Mechanical-Hand level
	Lift speed(with load/withou load)				mm/s	350/400
	Travel speed (without load)				km/h	20
	Max. gradeability (with load)				%	28
Power, transmission and others	Engine	Model				YT4B2Z
		Manufacturer				YTO
		Rated power			kw	74.9/2400
	Gearbox	Transmission type				Hydraulic
	Gearbox	Gears,speed (front/rear)				Ⅱ/Ⅱ
	Tyre	type				Pneumatic tyres
		Model	Front			16/70-20-16PR
		Model	Rear			16/70-20/16PR
Others	Self.weight				kg	8300
	Free lift height			h4	mm	100
	Fork	Thickness×Width×Length		c×b×a	mm	60×150×1220
	Overall dimensions	Overall length(without forks)		L2	mm	4460
		Overall width		b1	mm	2165
			Lower height(mast)	h3	mm	2660
			Overhead guard	h7	mm	2550
	Min. turning radius			Wa	mm	5500
	Min. under ground clearance	Center of wheel-base		m2	mm	290
