SANY 300 Tons SAC3000 With 122m Lifting Boom Crane

SANY 300 Tons SAC3000 With 122m Lifting Boom Crane thumbnail-1
SANY 300 Tons SAC3000 With 122m Lifting Boom Crane thumbnail-2
SANY 300 Tons SAC3000 With 122m Lifting Boom Crane thumbnail-3
SANY 300 Tons SAC3000 With 122m Lifting Boom Crane photo-1
SANY 300 Tons SAC3000 With 122m Lifting Boom Crane photo-2
SANY 300 Tons SAC3000 With 122m Lifting Boom Crane photo-3
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Hoising constuction
Rated Loading Capacity:
300 ton
Contact Supplier Request Quote Chat Now
Evangel Industrial (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Hoising constuction
Rated Loading Capacity 300 ton
Rated Lifting Moment 8800KN.m
Max. Lifting Load 300ton
Max. Lifting Height 122m
Span 8.95*8.6m
Place of Origin Hunan, China
Brand Name SANY
Model Number SAC3000
Certification ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

SANY 300 tons SAC3000 with 122m lifting boom crane

 For further good price,please contact

Whatsapp :+86-18202126581
Skype:sunchinali
Mobile: +86-18202126581
Email:martin @





Excellent and stable chassis performance

The use of innovative 6-axle chassis design with six driving modes and four braking modes provides more reliable traveling performance. High stability and safety are guaranteed with tipping over early-warning technology.

Efficient and energy-saving hydraulic control

Self-developed dual-pump converging / diversion main valve is used. Converging flow of the single-action dual-pump ensures fast operation and high work efficiency; combined-action dual pump diversion system is applied to ensure stable controllability.

Electric proportional variable displacement piston pump is used to ensure high-accurate flow control with higher efficiency and energy saving.

Ultra long boom for wide operating radius

Longest boom length is 80m and fixed jib is 42m, which ensures max. lifting height of 112m and max. working radius of 80m.

0°~ 40°automatic infinite variable luffing jib is applied to ensure convenient switching over between all operations with high efficiency.

Intelligent electronic control technology

The adoption of internationally advanced distributed integration bus data communication network and the configuration of abundant sensing elements can achieve timely feedback of data information and monitor the overall working status in real-time.

The human-computer interaction interface is used to meet with customer’s individual requirements


Max. lifting capacity
300t

Overall length
18200mm
Overall width
3000mm
Overall height
4000mm
Axles
6
Axle distance-1,2
1650mm
Axle distance-2,3
3170mm
Axle distance-3,4
1650mm
Axle distance -4, 5
2440 mm
Axle distance -5, 6
1650 mm

Overall weight
72000 kg
Front axle load
12000 kg
Rear axle load
12000 kg

Model
Germany brand
Rated power
440 kW/1800rpm
Rated torque
2800 N.m/ 1300 rpm
Rated power-superstructure
205kw/2200rpm
Rated torque-superstructure
1100N.m/1200-1600rpm
Emission standard
Euro IV

Max. traveling speed
80 km/h
Min.turning radius
12 m
Min.turning radius of boom head
14.4 m
Drive train
12 × 8
Min. ground clearance
360 mm
Approach angle
16°
Departure angle
18°
Max. gradeability
49%
Fuel consumption per 100km
≤ 114 L

Temperature range
– 20 ℃ - + 50 ℃
Min.lifting radius
3 m
Tail swing radius of superstructure
5735 mm
Boom section
6
Boom shape
U-shaped
Max. lifting moment-Base boom
8800 kN·m
Max. lifting moment-Full-extend boom
3640 kN·m
Max. lifting moment-Full-extend boom+jib
884 kN·m
Length-Base boom
15.65 m
Length-Full-extend boom
73 m
Length-Full-extend boom+jib
115 m
Outrigger span(Longitudinal/Transversal)
8.95 × 8.6 m
Jib offset
0° 20° 40°

Max. single rope lifting speed of main winch(no load)
130 m/min
Max. single rope lifting speed of auxiliary winch(no load)
130 m/min
Full extend/retract time of boom
600 / 600 s
Full raise/lower time of boom
65 / 90 s
Swing speed
1.7 r/min

HVAC in up cab
Cooling/Heating
HVAC in low cab
Cooling/Heating
