SAC2200C SANY All Terrain Crane Sale

SAC2200C SANY All Terrain Crane Sale thumbnail-1
SAC2200C SANY All Terrain Crane Sale thumbnail-2
SAC2200C SANY All Terrain Crane Sale thumbnail-3
SAC2200C SANY All Terrain Crane Sale thumbnail-4
SAC2200C SANY All Terrain Crane Sale thumbnail-5
SAC2200C SANY All Terrain Crane Sale thumbnail-6
SAC2200C SANY All Terrain Crane Sale photo-1
SAC2200C SANY All Terrain Crane Sale photo-2
SAC2200C SANY All Terrain Crane Sale photo-3
SAC2200C SANY All Terrain Crane Sale photo-4
SAC2200C SANY All Terrain Crane Sale photo-5
SAC2200C SANY All Terrain Crane Sale photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Hoising constuction
Rated Loading Capacity:
220 ton
Contact Supplier Request Quote Chat Now
Evangel Industrial (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Hoising constuction
Rated Loading Capacity 220 ton
Rated Lifting Moment 7271KN.m
Max. Lifting Load 220ton
Max. Lifting Height 114.5 m
Span 9.0m*8.5m
Place of Origin Hunan, China
Brand Name SANY
Model Number SAC2200C
Certification ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

SAC2200C SANY all terrain crane sale

Further good price,please contact

Whatsapp :+86-18202126581
Skype:sunchinali
Mobile: +86 18202126581
Email:martin @





Energy-saving hydraulic control technology
The SAC2200C features Sany own self-developed dual-pump converging / diversion main valve. Converging flow of the single-action dual-pump ensures fast operation and high work efficiency, It can achieve the converging flow of 520L/min.

Combined-action dual-pump diversion system is applied to ensure stable controllability. An electric proportional variable piston pump is used to ensure high-accurate flow control and higher efficiency and energy saving.

Safe and intelligent electronic control
By using a world-class distributed integration bus data communication network and configuring the sensors, the SAC2200C can respond with quick feedback of data and monitor the overall working status in real-time.

The human-computer interaction interface can easily satisfy a customer's individual requirements.

More safety Devices
The voice alarm, anti-rollover function and ABS are used to give more protection.

Lifting expert system

The lifting expert system can provide and choose the best suitable lifting plan to ensure the stability and safety of the construction.

Max. lifting capacity
220t

Overall length
15530mm
Overall width
3000mm
Overall height
4000mm
Axles
5
Axle distance-1,2
2750mm
Axle distance-2,3
1650mm
Axle distance-3,4
2490mm
Axle distance -4, 5
1650 mm

Overall weight
60000 kg
Front axle load
12000 kg
Rear axle load
12000 kg

Model
BENZ
Rated power
390 kW/1800rpm
Rated torque
2400 N.m/ 1100 rpm
Emission standard
Euro Ⅲ

Max. traveling speed
81 km/h
Min.turning radius
10 m
Min.turning radius of boom head
11 m
Drive train
10 × 8
Min. ground clearance
325 mm
Approach angle
20 °
Departure angle
17 °
Max. gradeability
58%
Fuel consumption per 100km
≤ 72 L

Temperature range
– 20 ℃ ~ + 40 ℃
Min.lifting radius
3 m
Tail swing radius of superstructure
4.85 m
Boom section
6
Boom shape
U-shaped
Max. lifting moment-Base boom
7271 kN·m
Max. lifting moment-Full-extend boom
3540 kN·m
Max. lifting moment-Full-extend boom+jib
952 kN·m
Length-Base boom
13.5 m
Length-Full-extend boom
62 m
Length-Full-extend boom+jib
103.5 m
Outrigger span(Longitudinal/Transversal)
9.0 × 8.5 m
Jib offset
0°~40°

Max. single rope lifting speed of main winch(no load)
130 m/min
Max. single rope lifting speed of auxiliary winch(no load)
130 m/min
Full extend/retract time of boom
550 / 550 s
Full raise/lower time of boom
60 / 90 s
Swing speed
1.8 r/min

HVAC in up cab
Cooling/Heating
HVAC in low cab
Cooling/Heating

SAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane saleSAC2200C SANY all terrain crane sale
