2017 SANY 2t Capacity Excavator SY20C

2017 SANY 2t Capacity Excavator SY20C photo-1
2017 SANY 2t Capacity Excavator SY20C photo-2
2017 SANY 2t Capacity Excavator SY20C photo-3
2017 SANY 2t Capacity Excavator SY20C photo-4
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
SANY
Model Number:
SY20C
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hunan, China
Brand Name SANY
Model Number SY20C
Condition New
Moving Type Crawler Excavator
Operating Weight 1820kg
Bucket capacity 0.06cbm
Maximum Digging Height 3665mm
Maximum Digging Depth 2360mm
Machine Weight 2 ton
Max Digging Radius 6240mm
Rated Speed 4.4/2.4(Highest/Lowest)km/h
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

2017 SANY 2t capacity excavator SY20C



 SY20C mini excavator (1.75 ton excavator) features optimized controllability with the application of mature load sensing system and independently developed hydraulic commissioning technique.

Superior Performance

SY20C 1.75 ton excavator adopts 10.3/2200KW/rpm engine and optimized power matching technology, providing efficient, economical and reliable performance for the toughest of jobs.

The Tier 3 engine is environmentally friendly, highly efficient, and low emissions.

High Stability and Reliability

All the parts have been strengthened, especially the working devices such as the bucket, the boom and the crawler belt.

With extended boom and reinforced undercarriage, the machine can provide stable performance in various complicated working environments.

User Friendly Design

Being compact, the machine is very flexible and can work in a narrow jobsite.

Its load sensing system and automated technology make the operation easier.

The ergonomic design in the cab like the chair, the joystick and the standard canopy with newly-designed damping system give the operator a comfort experience.

The alert and monitoring system gives real-time feedback about the machine's dynamics, highly improving the safety of both the operator and the machine.

Engine model
 3TNV70-SSU
Rated power
10.3KW/2200rpm
Displacement
0.854L
Emission standard
Tier 3
Operation Range
Operating weight
1820kg
Max. digging height
3665mm
Max. dumping height
2635mm
Max. digging depth
2360mm
Max. vertical digging depth
2215mm
Max. digging reach
3900mm
Min. swing radius
1655mm
Dimensions
Transport length
3575mm
Transport width
980mm/1350mm
Transport height
2420mm
Min. ground clearance
180mm
Undercarriage/Working Device
Std. track shoe width
230mm
Bucket capacity
0.06 m³
Track gauge
750mm/1120mm
Boom length
1810 mm
Arm length
1130 mm
Performance
Travel speed
3.7/2.1KM/h
Swing speed
10rpm
Gradeability
70%/35°
Ground pressure
29.1kpa
Bucket digging force
15.2KN
Arm digging force
9.2KN
Fuel tank capacity
23L
Hydraulic tank capacity
21L
