Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > Top Quality 1800kg SANY Mini Crawler Excavator SY16C
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
SANY
Model Number:
SY16C
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2017 Sale SANY 5 Tons Crawler Excavator Construction Use SY55CNegotiableMOQ: 1 Unit -
SY80C SANY 8t Crawler Excavator in Good ConditionNegotiableMOQ: 1 Unit
-
Liugong 36t Hydraulic Excavator With Best PriceUS$ 1 - 250,000MOQ: 1 Unit
-
Liugong Excavator 30 Ton Load Capacity CLG930EIIUS$ 1 - 185,000MOQ: 1 Set
-
Liugong CLG925DII New and Used Excavator for SaleUS$ 1 - 125,000MOQ: 1 Set
Place of Origin
Hunan, China
Brand Name
SANY
Model Number
SY16C
Condition
New
Moving Type
Crawler Excavator
Operating Weight
1800kg
Bucket capacity
0.04cbm
Maximum Digging Height
3665mm
Maximum Digging Depth
2360mm
Machine Weight
1800kg
Max Digging Radius
4000mm
Rated Speed
3.7/2.1(Highest/Lowest)km/h
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Top Quality 1800kg SANY mini crawler excavator SY16C
High efficiency and reliability
The customized Isuzu 4JG1 Engine with Tier 3 emission standard shows extra-strong working power, ensuring the high reliability especially in the tough working environment.
The strengthened bucket uses wearing-resisting steel plate in its bottom, and the optimized arc shape reduces the digging resistance and abrasion caused by the rocks.
Comfortable operation and easy maintenance
The spacious view and suspension seat design, together with the damping and noise-reduction performance, gives the operator more confortable experience.
The large covering parts makes the maintenance more easily and approachable.
Engine model
3TNV70-SSU
Rated power
10.3 kW/2200 rpm
Max.torque
51.8 Nm/1800 rpm
Displacement
0.993 L
Emission standard
Tier 4 final
Operation Range
Operating weight
1820 kg
Max. digging height
3665 mm
Max. dumping height
2635 mm
Max. digging depth
2360 mm
Max. vertical digging depth
2215 mm
Max. digging reach
4000 mm
Min. swing radius
1655 mm
Height at min.swing radius
2745 mm
Dimensions
Transport length
3575 mm
Transport width
980/1350 mm
Transport height
2420 mm
Upper width
980 mm
Blade height
270-310 mm
Tail swing radius
920 mm
Min. ground clearance
180 mm
Undercarriage/Working Device
Std. track shoe width
230 mm
Bucket capacity
0.04 m3
Track gauge
750/1120 mm
Roller gauge
1225 mm
Boom length
1810 mm
Arm length
1130 mm
Performance
Travel speed
3.7/2.1 km/h
Swing speed
10 rpm
Gradeability
58%/30°
Ground pressure
29 kPa
Bucket digging force
15.2 kN
Arm digging force
9.2 kN
Fuel tank capacity
23 L
Hydraulic tank capacity
21 L
