SANY SR150C Full Hydraulic Rotary China drilling rig sale good price
SANY Popular Rotary Drilling Rig SR150C
1.Operating weight 45000kg
2.Max.drill diameter 1500mm
3.Max.drill depth: 55m
SANY Popular Rotary Drilling Rig SR150C with High Quality
1.Operating weight 45000kg
2.Max.drill diameter 1500mm
3.Max.drill depth: 55m
5-level anti-vibration technology absorbs drilling vibrational frequency all- directionally to guarantee high stability; The special lubricating system makes sure that it can work in high-temperature environment. Rotary drive is available in three drilling modes-standard, low speed and big torque or high speed and small torque; spin-off is optional; The removable key of rotary drive and symmetry structure design double its service life; The main winch has highlights of touch-bottom protection, priority control and fast line speed; Crowd cylinder has two operation modes---normal lifting and fast lifting to improve push efficiency; Mast features automatic erecting, lying and vertical adjustment to ensure the accuracy requirements in construction; Balance control system of the whole machine is available.
Parameter
| SR150C | Unit | Parameters |
| Max.Drilling Dia. | mm | 1500 |
| Max.Drilling Depth | m | 55 |
| largest torque | kN.m | 150 |
| Speed of rotary drive totation | rpm | 7-14 |
| Max.push | kN | 150 |
| Max.pull | kN | 160 |
| Crowd stroke | mm | 4250 |
| Mast sideward | . | (+/-)5 |
| Mast forward | . | 5 |
| Main winch pull(1st layer) | kN | 160 |
| Main winch wire rope dia. | mm | 28 |
| Max.main winch line speed | m/min | 70 |
| ch pull(1st layer) | kN | 60 |
| ch wire rope dia. | mm | 14 |
| Engine | CC-6BG1TRP |
| Engine power | KW(HP) 125 (168) @2100rpm |
| Style | 4-storke,water-colled,overhead value type and electronic injection |
| Intake form | Turbocharged, inter cooling |
| Fuel | Diesel oil |
| Emission regulation | EU stage II/EPA Tier 2 |
| No of cylinder-bore*stroke | 6-105mm X 125mm |
| Displacement | 6.494 |
| Compression ration | 17.5:1 |
| Rated power | 125KW @ 2100rpm |
| 168HP @ 2100rpm | |
| Max. output torque | 637.9N.m @ 1800rpm |
| 864lbf.ft @ 1800rpm |
