SHACMAN Hydraulic Pump for Dump Truck SX3255DR464C

Name: SHACMAN Hydraulic Pump for Dump Truck SX3255DR464C
Brand: SHACMAN
SKU: 140721646
Availability: InStock

US$ 10,000 - 100,000 MOQ: 1 Unit

Key Specifications

Drive Wheel:

6x4

Capacity (Load):

21 - 30t

Horsepower:

251 - 350hp

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai tianjin qingdao

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 6x4

Capacity (Load) 21 - 30t

Horsepower 251 - 350hp

Condition New

Transmission Type Automatic

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity 6 - 8L

Gross Vehicle Weight 25000

Place of Origin Shanxi, China

Brand Name SHACMAN

Model Number SX3255DR464C

Dimensions (L x W x H) (mm) 9630x2490x3450mm

SHACMAN hydraulic pump for dump truck SX3255DR464C

Product Description

Model			SX3255DR464C
Traction type			6X4
Driving type			Left hand driving(RHD is optional)
Overall Dimension(LxWxH)			9630x2490x3450
Wheel base(mm)			4575+1400mm
Curb weight(kg)			12400
Total weight(kg)			25000
Payload(tons)			25-35
Engine Steyr technology, made in China	ISME345 30		Diesel, 4-stoke Direct injection,6-cylinder in Line, radiator, turbo-charging
	Displacement(L)		10.8
	Bore X stroke (mm)		126mm/130mm
	Max power(kw/rpm)		345HP/254kW
	Max torque(Nm/rpm)		1710NM@1000-1200/rpm
	Emission		EUROIII
Fuel tanker(L)			400 Aluminum fuel tank
Gearbox		Brand	Fuller (Fast)
		Model	12JSD160T
		Shift mode	12 forward speeds; 2 reverse speeds
Steering system		Model	ISME345
Clutch		Model	430 Diaphragm type
Frame		850×300(8+7)
Front axle		9.5T technology front non-driving steering axle
Middle and Rear axle		16T technology double reduction driving axle Ratio:5.92
Tyre		12.00R20
Number of tyre		12+1 spare
Suspension		Leaf spring type
		Front/rear: 10/12
Color		optional
Electrical		Battery		2x12V/135Ah
		Generator		28V-35A
		Starter		5.4Kw/24V
Cabin		Shacman standard cab, 2 seats,A/C and ABS without sleep.
Body
