Home > Manufacturing & Processing Machinery > Crane > Other Cranes > ZOOMLION 55 Ton QUY50 Crawler Crane 150 Ton Crawler Crane Rental

ZOOMLION 55 Ton QUY50 Crawler Crane 150 Ton Crawler Crane Rental

Name: ZOOMLION 55 Ton QUY50 Crawler Crane 150 Ton Crawler Crane Rental
Brand: Zoomlion
SKU: 140721344
Availability: InStock

US$ 10,004 - 65,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Construction

Rated Loading Capacity:

50 ton

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Construction

Rated Loading Capacity 50 ton

Max. Lifting Load 50 ton

Max. Lifting Height 52m

Span 12m

Place of Origin Hunan, China

Brand Name Zoomlion

Model Number QUY50

Certification ISO9001

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

ZOOMLION 55 ton QUY50 Crawler Crane 150 ton crawler crane rental

whatsApp/Tel:+86 18217056032

Item		Value	Remarks
Max. lifting capacity × Radiust ×m		55×3.7
Deadweight with basic boomt		48
Main boom lengthm		13~52
Fixed jib lengthm		6~15
Max. lifting capacity of fixed jibt		5
Offset angle of fixed jib°		10,30
Max. length of main boom with fixed jibm		43+15
Max. speed of single rope on drum	Main winchm/min	120	The 4^th rope layer
	Auxiliary winchm/min	121	The 4^th rope layer
	Derricking winchm/min	60	The 4^th rope layer
Slewing speedrpm		0~3.0
Traveling speedkm/h		0~1.6
Gradeability%		40
Ground pressureMPa		0.066
Overall dimensions (L×W×H)mm		6800×3300×3020
Engine	Rated power/ rotational speedkW/rpm	132/2200
	Max. output torque/ rotational speedNm/rpm	750/1300
	Emission standard	EU Stage Ⅲ
