Manual Hydraulic Forklift YTO Forklift Battery CPQD30 Prices

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

US$ 8,000 - 15,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

YTO

Payment & Shipping

Payment Methods:

Port of Shipment:

SAHNGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name YTO

Model Number CPQD30

Type Manual Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 3000kg

Max. Lifting Height 3000MM

Min. Lifting Height 85mm

Fork Length 920MM

Fork Width 100MM

Overall Dimensions 2070*1070*4020mm

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

Manual hydraulic forklift YTO forklift battery CPQD30 prices

Product Description

Model			CPQD20	CPYD20	CPQD25	CPYD25	CPQD30	CPYD30
Power type			Gasoline	LPG	Gasoline	LPG	Gasoline	LPG
Rated capacity		kg	2000	2000	2500	2500	3000	3000
Load center	d	mm	500	500	500	500	500	500
Lift height	h2	mm	3000	3000	3000	3000	3000	3000
Mast tilt angle (forward/backward)	α/β	Deg	6/12	6/12	6/12	6/12	6/12	6/12
Front overhang	L3	mm	465	465	465	465	485	485
Wheel-base	L4	mm	1600	1600	1600	1600	1700	1700
Tread(front/rear)	b4/b5	mm	960/970	960/970	960/970	960/970	1000/980	1000/980
Travel brake			Hydraulic-Foot pedal
Parking brake			Mechanical-Hand level
Lift speed(with/without load)		mm/s	440/500	440/500	440/500	440/500	360/450	360/450
Lower speed (with/without load)		mm/s	(with load)<600 ,(without load)>300
Travel speed (with/without load)		km/h	18/19	18/19	18/19	18/19	18/19	18/19
Max. gradeability (with load)		%	20	20	20	20	20	20
Max. Towing (with/without load)		kN	16/13	15/12	17/14	16/13	19/15	18/14
Weight Distribution with load(pront/rear)		kg	4665/635	4700/650	5455/745	5500/750	6350/870	6395/875
Weight Distribution without load(pront/rear)		kg	1255/2045	1270/2080	1400/2300	1425/2325	1600/2620	1620/2650
