YTO Hand Manual Forklift CPCD40 New Mini Forklift Price

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

US$ 20,000 - 40,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

YTO

Payment & Shipping

Payment Methods:

Port of Shipment:

SAHNGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name YTO

Model Number CPCD40

Type Manual Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 2500kg

Max. Lifting Height 3000MM

Min. Lifting Height 85mm

Fork Length 920MM

Fork Width 100MM

Overall Dimensions 2070*1070*4020mm

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

YTO hand manual forklift CPCD40 New Mini Forklift Price

Product Description

Phyllis Wang
Sales Manager
Skype: wang.phyllis01
Mobile: +86-157-371-37170

Model			CPCD10	CPCD15	CPCD20	CPCD25	CPCD30
Power type			Diesel	Diesel	Diesel	Diesel	Diesel
Rated capacity		kg	1000	1500	2000	2500	3000
Load center	d	mm	500	500	500	500	500
Lift height	h2	mm	3000	3000	3000	3000	3000
Mast tilt angle (forward/backward)	α/β	Deg	6/12	6/12	6/12	6/12	6/12
Front overhang	L3	mm	425	425	483	483	485
Wheel-base	L4	mm	1370	1370	1500	1500	1700
Tread(front/rear)	b4/b5	mm	890/920	890/920	970/950	970/950	1000/970
Travel brake			Hydraulic-Foot pedal
Parking brake			Mechanical-Hand level
Lift speed(with/without load)		mm/s	260/400	260/400	260/400	260/400	280/420
Lower speed (with/without load)		mm/s	(with load),600 <(without load)>300
Travel speed (with/without load)		km/h	11/12	11/12	11/12	11/12	13/15
Max. gradeability (with load)		%	15	10	10	10	13
Max. Towing (with/without load)		kN	6/5	6.5/5.5	9.4/7.5	9.8/8	11/9
Weight Distribution with load(front/rear)			3350/500	3900/600	5250/720	5900/840	6920/1080
Weight Distribution without load(front/rear)			1200/1650	1300/1700	1720/2250	1825/2415	2150/2850
